Specifications
1.flash dryer2.short drying time
3.widely used
4.Meet GMP
flash dryer
Applications
QG airsteam drying processor can meet different need of raw materials. Besides the mentioned raw materials in basic model, there are hyminal, A.B.C intermediate, white carbon black, tea, catalyst of oxalic acid, promote agent m,m.d, catalyst, deposited carbon powder, N-acetyl-sulfanily chloride, p-aminosalicylic acid, p-phthalic acid, diethyl aniline, titanium dioxide, active carbon, sodium fluosilicate, ammonium sulphate, powder of silicon glue, synthesis resin, calcium sulphate, pp resin, aureomycin, sodium polysilicate, oral glucose, sodium sulphate, mine of sulphate, mine of phosphorus, BB blue, melting phosphours fertilizer, tetracycline, ferric oxide, calcium carbonate, titanium/ferric mine, copper mine, powder of white potato, tail coal, stearate, zein, medicine, medical agent, ferric oxide, less residue and so on.
Principle
The material is promoted uniformity from the feed inlet. The powder material is improved quickly in pipe by hot air. The material discharged continuously after drying and separation. The drying time is generally several seconds.
Technical Parameters
Type |
Moisture to be evaporated(kg/h) |
Power(kw) |
Occupied area(m2) |
Height(m) |
QG50 |
50 |
7 |
20 |
14 |
QG100 |
100 |
13 |
32 |
14 |
QG200* |
200 |
21 |
40 |
15 |
QG250 |
250 |
24 |
64 |
15 |
QG500 |
500 |
43 |
96 |
18 |
QG1000* |
1000 |
100 |
120 |
18 |
QG1500* |
1500 |
150 |
200 |
20 |
