Water Tank Drawing Machine
US$ 15,000 - 60,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Inlet Diameter:
8mm
Outlet Diameter:
1.2mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or as ur need
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Tire Wire Drawing MachineUS$ 12,000 - 20,000MOQ: 1 Set -
Water Tank Drawing MachineUS$ 12,000 - 25,000MOQ: 1 Set
-
Water Tank Wire Drawing MachineUS$ 10,000 - 25,000MOQ: 1 Set
-
Expensive Alloy Wire Drawing MachineUS$ 12,000 - 30,000MOQ: 1 Set
-
Steel Fiber Wire Drawing Machine LT160-21-275US$ 15,000 - 25,000MOQ: 1 Set
Condition
New
Inlet Diameter
8mm
Outlet Diameter
1.2mm
Place of Origin
Jiangsu, China
Brand Name
wanyi
Model Number
LT13-450
Voltage
380/220v
Power(W)
75KW
Dimension(L*W*H)
5x4x3m
Weight
2000kg
Certification
ce
Warranty
one year freely
After-sales Service Provided
Engineers available to service machinery overseas
Inlet wire |
8mm |
|
Outlet wire |
1.2-4.0mm |
|
Max speed of drawing |
20m/s |
|
Drawing block size |
450mm |
|
Max number of passes |
13 |
|
Die dimension |
38×25 |
|
Capacity of the accumulator |
7m |
|
Dual-reel spooling bobbin size |
PND500~PND630 |
|
Main motor power |
28kW (DC) |
|
Power of motor for constant speed wheel |
75kW (DC) |
|
Power of motor for dual-reel take up |
30kW×2 (DC ) |
|
Machine dimension |
2800×4200×5000mm |
|
Coiling machine quote by optional |
900mm For option |
|
Anneal unit power |
70V,5000A(DC) |
|
