Home > Manufacturing & Processing Machinery > Machine Tools > Special Machine Tools > Steel Fiber Wire Drawing Machine LT160-21-275
Steel Fiber Wire Drawing Machine LT160-21-275
US$ 15,000 - 25,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Place of Origin:
Jiangsu, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or as u need
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
CNC or Not
Normal
Place of Origin
Jiangsu, China
Brand Name
wanyi
Model Number
LT160-21-275
Voltage
380v
Power(W)
22kw
Dimension(L*W*H)
1300x1200x1400mm
Weight
2500KG
Certification
SGS or CE
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
| Skill position | Skill parameter |
| product type | wet drawing 4 groups of capstan |
| Produce materials | high carbon steel wire |
| No.of drafts | 21 |
| Max.speed | 20m/s |
| Inlet wire diameter | φ0.8mm-φ1.5mm |
| Outlet wire diameter | φ1.5mm-φ0.3mm |
| Reduction perdraft | 14.5% |
| ou perdraft | 97% |
| Inlet wire strength | 1250MPa |
| Capstan surface status | WC |
| Rigidity of capstan surface | 62-64HRC |
| Cooling type | Circulaing cooling |
| Motor power | 22KW |
| Speed control | Energy-saving convernor motors |
| Motor power | PLC contorl |
| Turn control | ≤200N |
| Noises | ≤85dB |
| Volume of cooling box | 600L |
| Measure memts | 1700*1600*1910 |
| Weight | 2000kg |
