Mild Wire Drawing Machine LZ4/400
US$ 30,000 - 55,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wire Drawing Machine
Use:
Wire
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or as u need
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fine Wire Drawing MachineUS$ 15,000 - 35,000MOQ: 1 Set -
Submerged Arc Wire Drawing MachineUS$ 20,000 - 50,000MOQ: 1 Set
-
E71T-1 Flux Cored Wire Drawing MachineUS$ 40,000 - 80,000MOQ: 1 Set
-
Straight Line Wire Drawing MachineUS$ 20,000 - 60,000MOQ: 1 Set
-
SAE1006 Wire Drawing Machine LineUS$ 25,000 - 70,000MOQ: 1 Set
Condition
New
Type
Wire Drawing Machine
Use
Wire
Place of Origin
Jiangsu, China
Brand Name
wanyi
Model Number
LZ4/400
Voltage
380V
Power(W)
7.5KW-45KW
Dimension(L*W*H)
8500X1560X1600MM
Weight
6500kg
Certification
CE SGS
Warranty
one year freely
After-sales Service Provided
Overseas service center available
Main Technical Parameters |
|
|
|
||
Specifications |
No.of drafts |
Max.inlet wire(mm) |
duction(mm) |
Motor power(kw) |
Production speed(m/s) |
300 |
8~12 |
2.5 |
0.4 |
3~4.5 |
25 |
350 |
8~12 |
3.5 |
0.6 |
5.5~11 |
25 |
400 |
8~12 |
4.2 |
0.75 |
7.5~15 |
25 |
450 |
8~12 |
4.5 |
0.96 |
15~22 |
18 |
600 |
6~10 |
6.5 |
1.4 |
22~37 |
16 |
