2YK1545 circular vibrating screening plant with low price
2YK1545 circular vibrating screening plant :
1. Vibrating screens use eccentric block to produce strong exciting force.
2. Crossbeam and the main body of the screen are connected with high strength screw bolts. So they have the features of simple structure and easy maintenance.
3. Vibrating Screen adopts tire coupling with capability of flexible connection and stable operation.
4. Vibrating Screens adopt the structure of small amplitude, high frequency, large obliquity to make the screen hold the capability of high efficiency, large handling capacity, long life span, low consumption, and little noise.
Circular vibrating screen application:
Vibrating Screen are widely used for grading and screening materials in such fields as chemical industry, minerals, quarry, water conservancy and hydropower, transportation, smelting and so on. Vibrating Screen are efficient screening machines for the classification of bulk material such as coal, minerals, coke etc. There are 35 specifications for this series Vibrating Screen, of which the heavy duty type of Vibrating Screen are for the classification of large size materials, while the light duty type of Vibrating Screen are for the middle and small size materials.
Circular vibrating screen working principle:
It adjusts the amplitude by tube-shaped violent vibration screen of eccentricshaft and eccentric blocks. The body moves like a circle, in order to make the materials screened. the deck can be one layer,two layer ,three layer or four layers according to the output size.
Circular vibrating screen features:
1. High vibrating force with unique eccentric structure. Adopt advanced construction, making the vibrating force powerful.
2. The beam and case of the screen are connected with high strength bolts without welding.
3. Simple structure, easy to repair.
4. Adopt tire coupling and soft connection makes operation smooth.
5. High efficiency, easy maintenance, sturdy and durable.
Circular vibrating screen main technical parameters:
Model |
Sieve lay-er |
Sieve area (m2) |
Mesh size (mm) |
Max feedin-g size (mm) |
Capacity (m3/h) |
Vibrating frequency (r/min) |
Motor power (kw) |
Weight (kg) |
Sieve spec. (mm) |
YK1236 |
1 |
4.2 |
3-100 |
300 |
30-160 |
970 |
5.5 |
3210 |
1180×3550 |
3YK1236 |
3 |
4.2 |
3-100 |
300 |
30-160 |
970 |
11 |
4110 |
1180×3550 |
2YK1245 |
2 |
5.3 |
3-100 |
300 |
35-180 |
970 |
11 |
4320 |
1180×4450 |
3YK1245 |
3 |
5.3 |
3-100 |
300 |
35-180 |
970 |
11 |
4460 |
1180×4450 |
YK1535 |
1 |
5.1 |
3-100 |
300 |
34-200 |
970 |
11 |
4680 |
1480×3450 |
3YK1535 |
3 |
5.1 |
3-100 |
400 |
34-200 |
970 |
15 |
5710 |
1480×3450 |
YK1545 |
1 |
6.6 |
3-100 |
400 |
44-200 |
970 |
11 |
4300 |
1480×4450 |
2YK1545 |
2 |
6.6 |
3-100 |
400 |
44-258 |
970 |
15 |
4830 |
1480×4450 |
3YK1545 |
3 |
6.6 |
3-100 |
400 |
44-258 |
970 |
15 |
5832 |
1480×4450 |
4YK1545 |
4 |
6.6 |
3-100 |
400 |
44-258 |
970 |
18.5 |
6070 |
1480×4450 |
3YK1548 |
3 |
7.03 |
3-100 |
400 |
47-275 |
970 |
15 |
6540 |
1480×4750 |
4YK1548 |
4 |
7.03 |
3-100 |
200 |
47-275 |
730 |
18.5 |
6850 |
1480×4750 |
YK1848 |
1 |
8.5 |
3-100 |
400 |
56-330 |
755 |
15 |
6189 |
1780×4750 |
2YK1848 |
2 |
8.5 |
3-100 |
400 |
56-330 |
750 |
18.5 |
6539 |
1780×4750 |
3YK1848 |
3 |
8.5 |
3-100 |
400 |
56-330 |
970 |
22 |
6935 |
1780×4750 |
2YK1854 |
2 |
9.5 |
3-100 |
400 |
63-450 |
970 |
22 |
7220 |
1780×5350 |
3YK1854 |
3 |
9.5 |
3-100 |
400 |
63-450 |
970 |
22 |
7640 |
1780×5350 |
YK1860 |
1 |
10.6 |
3-100 |
400 |
56-450 |
970 |
18.5 |
7200 |
1780×5950 |
2YK2160 |
2 |
12.4 |
3-100 |
400 |
80-720 |
970 |
30 |
8240 |
2080×5950 |
3YK2160 |
3 |
12.4 |
3-100 |
400 |
80-720 |
970 |
30 |
8800 |
2080×5950 |
2YK2460 |
2 |
14.2 |
3-100 |
400 |
80-800 |
970 |
30 |
9120 |
2380×5950 |
3YK2460 |
3 |
14.2 |
3-100 |
400 |
80-800 |
970 |
30 |
9600 |
2380×5950 |
Factory show :
