Cement spiral conveyor for concrete mixing station:
1. Spiral conveyor Application:
Spiral conveyor is widely used in various industries, such as building materials, chemical industry, electric power, metallurgy, mine, coal, grain etc.It applies to all kinds pf powder ,and small block grannlar materials , such as pulverized coal , gravel , sand and lump coal , cement , grains , etc ., does not apply to transfer easily degenerate , viscous large and easy to agglomeration of materials , Screw conveyor working environment temperature should be -20---+50°C range , the transportation of materials temperature below 200°C, the largest dip 20°.
2. Technical data of the spiral conveyor:
Model |
Transmission length(m) |
Capacity(t/h) |
Power |
Weight |
||
Coal |
Cement |
Raw Material |
(kw) |
(t) |
||
GX200*10M |
3--70 |
8.5 |
7.9 |
7.3 |
2.2 |
0.7 |
GX250*10M |
3--70 |
16.5 |
15.6 |
13.8 |
3 |
0.95 |
GX300*10M |
3--70 |
20 |
21 |
18.7 |
3 |
1.4 |
GX400*10M |
3--70 |
54 |
51 |
45 |
5.5 |
2.1 |
GX500*10M |
3--70 |
79 |
84.4 |
74 |
7.5 |
3.2 |
