LSX spiral ore washer machine :
Spiral Ore Washer is also called Ore washer,Launder Washer. is used for cleaning sediment of iron, manganese, limestone, or tin that contains much mud before mine selection.
Screw Ore Washer/spiral ore washer is used for cleaning sediment of iron, manganese, limestone, or tin that contains much mud before mine selection. The main functions of this wash mine machine are mixing, washing, separating and desliming minerals. It is also applied in construction or power station project for cleaning stone with washing hydraulic pressure less than 147-196kpa.
working principle of spiral ore washer machine :
when the machine is working, the material goes into the input part. it will push the material to the output through the machine. surface dust and impurity are removed when the material from the input part to the output part is pushed, mixed and washed. the final product goes out through the discharge outlet and the mud and impurity will go out through overflow part.
Spiral ore washer machine features:
1-high level cleaning and reasonable structure.
2-large capacity and small power consumption
3-small loss of sand during the process of sand washing.
Spiral ore washer machine technical parameters:
| Model | Screw Diameter (mm) | Tank Length (mm) | Screw Quantity | Max Feeding (mm) | Capacity (t/h) | REV (r/min) | Power (kw) | Motor Model | Water Consumption (t/h) | Machine Size (mm) |
| LSX920 | 920 | 7585 | 1 | ≤10 | 100 | 21 | 6-11 | Y160L-6/11 | 10-80 | 8420×2180×3960 |
| 2LSX920 | 920 | 7580 | 2 | ≤10 | 200 | 21 | 6-11×2 | Y160L-6/11 | 20-160 | 8420×3970×3960 |
| LSX1120 | 1120 | 9750 | 1 | ≤10 | 175 | 17 | 6-18.5 | Y200L1-6/18.5 | 20-150 | 10770×3950×4860 |
| 2LSX1120 | 1120 | 9750 | 2 | ≤10 | 350 | 17 | 6-18.5×2 | Y200L1-6/18.5 | 40-300 | 10770×5260×4860 |
