Energy Saving Limestone Dry Grinding Ball Mill

Henan Lanji Machinery Manufacturing Co., Ltd.
Energy Saving Limestone Dry Grinding Ball Mill thumbnail-1
Energy Saving Limestone Dry Grinding Ball Mill thumbnail-2
Energy Saving Limestone Dry Grinding Ball Mill thumbnail-3
Energy Saving Limestone Dry Grinding Ball Mill thumbnail-4
Energy Saving Limestone Dry Grinding Ball Mill photo-1
Energy Saving Limestone Dry Grinding Ball Mill photo-2
Energy Saving Limestone Dry Grinding Ball Mill photo-3
Energy Saving Limestone Dry Grinding Ball Mill photo-4
US$ 8,000 - 80,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Ball Mill, small ball mill
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Ball Mill, small ball mill
Motor Type AC Motor
Power(W) 18.5-1250
Capacity(t/h) 0.65-2
Place of Origin Henan, China
Brand Name Lanji
Model Number 900*1800
Dimension(L*W*H) 5.0*2.0*2.1 m
Weight 3.6 t
Certification ISO9001:2000
Warranty 1 year including wearing parts
After-sales Service Provided Engineers available to service machinery overseas

Energy saving limestone dry grinding ball mill :



Limestone ball mill :

1.simple structure ball mill

uced consumption by 30%

3.increased capacity by 20%

4.Improve fineness



Energy saving limestone dry grinding ball millEnergy saving limestone dry grinding ball mill

dry grinding Limestone ball mill features:

1)New type on improved on the old type 2) Large diameter double roe self-aligning roller bearings



3) The whole rack, easy to install 4) By adopting an integral steel under-frame,installation precision is high.

dry grinding Limestone ball mill working principle:

ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

Energy saving limestone dry grinding ball mill

Limestone ball mill main technical parameters:



ModelCylinder rotary speed(r/min) Loading ball weight(t)Input size(mm)Discharge size(mm)Capacity(t/h)Motor power (kw)Weight (t)
Ø900×1800391.5≤200.075-0.890.8-218.54.6
Ø900×3000392.7≤200.075-0.891~4225.6
Ø1200×4500325≤250.074-0.41.6-5.85513.8
Ø1500×3000277.5≤250.074-0.42~57515.6
Ø1500×57002812≤250.074-0.43.5-613024.7
Ø1830×30002511≤250.074-0.44~1013028
Ø1830×64002421≤250.074-0.47~1621034
Ø2100×36002319≤250.074-0.410-3621046
Ø2200×45002127≤250.074-0.412~2328048.5
Ø2200×65002135≤250.074-0.414-2638052.8
Ø2200×70002135≤250.074-0.415-2838054
Ø2200×75002135≤250.074-0.415-3038056
Ø2400×45002130≤250.074-0.418-4532065
Ø2700×36002139≤250.074-0.419-7540083
Ø2700×45002048≤250.074-0.422-8543089
Ø3200×45001865≤250.074-0.429-140800137
Ø3200×54001881.6≤250.074-0.430-180800-1000146
Ø3600×45001788≤250.074-0.435-2101000190
Ø3600×850017144≤250.074-0.445-2601800260

 Energy saving limestone dry grinding ball millEnergy saving limestone dry grinding ball mill

 Energy saving limestone dry grinding ball mill



 Energy saving limestone dry grinding ball mill

Energy saving limestone dry grinding ball mill
