Mining ore vibrating feeder machine GZD series
- 50 Set / Sets per Month
- Qingdao Shanghi
- T/T D/P D/A Credit Card
- ZSW850 Electromagnetic Mining Vibrating Grizzly Screen Feeder Price
- Hanging Vibrating Feeder Screw ZSW Series Vibration Feeder For Quarry Stone
- Coal Mining Industry Vibratory Feeder Industrial And Vibrating Feeder Capacity Calculation
- Vibratory Feeder Industrial And Vibratory Feeder Controller Price
- Vibratory Feeder Industrial And Vibrating Feeder Capacity Calculation
- Mining Selecting Vibratory Feeder Industrial For Sale
Product Details
Condition: | New | Application: | ore feeding | Power Type: | Electric |
Capacity(t/h): | 30-50 t/h | Place of Origin: | Henan, China | Brand Name: | Lanji |
Model Number: | 800*700 | Power(W): | 3-50 Kw | Dimension(L*W*H): | 6.0*1.5*1.6m |
Weight: | 0.5-50 T | Certification: | ISO9001 | Warranty: | 2 Years |
After-sales Service Provided: | Overseas service center available |
Product Description
Mining ore vibrating feeder machine GZD series:
Feed Size : 400mm
Capacity 50-500t/h
Mining vibrating feeder Application Fields : Widely used in metallurgy, coal mine, mineral dressing, building materials, chemical, abrasive and other industries crushing and screening combined equipments
Vibrating feeder in the production process, can be massive, granular materials from storage bin evenly, regularly and continuously to into the feeding device, can be broken in the sand and gravel production line machinery and continuous evenly feed, and the material is coarse screening.
Vibrating feeder working principle:
Vibrating Feeder drives the screen, vibrator to make continuous circular motion by centrifugal force which is generated from the eccentric block rotating. And then the materials make continuously throwing motion on the oblique screen surface and are sending to the feeding opening evenly and continuously.
Main technical parameters of The Mining Vibrating Feeder:
Model | Hopper dimensions (mm) | Max feeding size (mm) | Output (t/h) | Power(kw) | Weight (kg) | Overall dimensions(mm) |
GZD-800*3000 | 850*3000 | 400 | 80-120 | 1.5*2 | 3895 | 3100*1800*1600 |
GZD-960*3800 | 960*3800 | 500 | 120-210 | 2.2*2 | 3980 | 3850*1950*1630 |
GZD-1100*4200 | 1100*4200 | 580 | 200-430 | 3.7*2 | 5570 | 4400*2050*1660 |
GZD-1100*4900 | 1100*4900 | 580 | 280-500 | 5.5*2 | 6520 | 5200*2050*1700 |
GZD-1300*5200 | 1300*4900 | 650 | 450-600 | 7.5*2 | 8200 | 5200*2350*1750 |
