Bentonite Jaw Crusher Machine for Sale

Bentonite Jaw Crusher Machine for Sale thumbnail-1
Bentonite Jaw Crusher Machine for Sale thumbnail-2
Bentonite Jaw Crusher Machine for Sale photo-1
Bentonite Jaw Crusher Machine for Sale photo-2
US$ 1,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Jaw Crusher
Application:
stone crushing
Contact Supplier Request Quote Chat Now
Henan Lanji Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Jaw Crusher
Application stone crushing
Motor Type DC Motor
Power(W) 7.5-100 KW
Capacity(t/h) 40-120
Place of Origin Henan, China
Brand Name Lanji
Model Number PE600*900
Dimension(L*W*H) all
Weight all, 17600kg
Certification ISO
Warranty 1year
After-sales Service Provided Engineers available to service machinery overseas

Bentonite jaw crusher machine for sale :



Stone Jaw crusher performance characteristics:



[1] .Low noise, less dust.



[2] .The big crushing ratio, uniform finished product size;



[3] .Has the advantages of simple structure, reliable work, low operation cost.



[4] .Discharge outlet adjustment range, can meet the requirements of different users;



[5] .Deep crushing cavity and no dead time, improves the feeding ability and yield;



[6] .The single life. Energy-saving equipment: energy 15% ~30%, more than double the system energy saving;



[7] .The lubrication system is safe and reliable, convenient for changing components, small maintenance workload;



[8] .The gasket type discharge opening adjusting device is convenient, reliable, large adjusting range, increase the flexibility of the device;

Jaw Crusher is mainly used to crush kinds of mining stones primarily, and the largest compression resistance of the material is 320MPa. The jaw crusher is widely used in stone mining, metallurgy industry, building material, highway, railway, and chemical industry.

Working Principle of Jaw Crusher:

The motor transmits power through belt, drives the moving jaw to do periodic motion towards the fixed jaw by the eccentric shaft. The angle between toggle plate and moving jaw plate increases when moving jaw moves . So the moving jaw moves towards the fixed jaw. The stuff will be crushed in this process. The angle between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw moves leaves fixed jaw by pulling rod and spring, the final crushed stuff will be discharged from the outlet.





 Bentonite jaw crusher machine for saleBentonite jaw crusher machine for sale

Technical data of jaw crusher:



Model

Feed opening size
(mm)

Max Feed
size
(mm)

Adjusting
range of discharge opening
(mm)

Capacity
(t/h)

Rotation speed of eccentric shaft
(r/min)

Motor power
(kw)

Total weight
(t)

Dimensions
(L*W*H)
(mm)

PE-150×250

150×250

125

10-40

1-3

250

5.5

0.8

720×660×850

PE-200×300

200×300

180

15-50

2-6

260

7.5

1.2

910×750×990

PE-200×350

200×350

180

18-70

3-10

260

11

1.5

1000×870×990

PE-250×400

250×400

210

20-60

5-20

300

15

2.8

1300×1090×1270

PE-400×600

400×600

340

40-100

16-60

275

30

7

1730×1730×1630

PE-500×750

500×750

425

50-100

40-110

275

55

12

1980×2080×1870

PE-600×750

600×750

500

150-200

80-240

275

55

15.8

2070×2000×1920

PE-600×900II

600×900

500

65-160

50-180

250

55

17

2190×2206×2300

PE-750×1060

750×1060

630

80-140

110-320

250

110

29

2660×2430×2800

PE-800×1060

800×1060

640

130-190

130-330

250

110

29.8

2710×2430×2800

PE-830×1060

830×1060

650

160-220

150-336

250

110

30.7

2740×2430×2800

PE-870×1060

870×1060

660

200-260

190-336

250

110

31.5

2810×2430×2800

PE-900×1060

900×1060

685

230-290

230-390

250

110

33

2870×2420×2940

PE-900×1200

900×1200

750

95-165

220-450

200

110

52

3380×2870×3330

PE-1000×1200

1000×1200

850

195-265

315-500

200

110

55

3480×2876×3330

PE-1200×1500

1200×1500

1020

150-350

400-800

180

160

100.9

4200×3300×3500

PE-1500×1800

1500×1800

1200

220-350

500-1000

180

280

122

5160×3660×4248

PE-1800×2100

1800×2100

1500

300-400

600-1200

160

400

150.6

6210×4013×4716

PEX-150×750

150×750

120

18-48

8-25

320

15

3.8

1200×1530×1060

PEX-250×750

250×750

210

25-60

13-35

330

30

5.5

1380×1750×1540

PEX-250×1000

250×1000

210

25-60

16-52

330

30

7

1560×1950×1390

PEX-250×1200

250×1200

210

25-60

20-61

330

37

9.7

2140×1660×1500

PEX-300×1300

300×1300

250

20-90

16-105

300

55

15.6

2720×1950×1600

 Bentonite jaw crusher machine for sale

                              Bentonite jaw crusher machine for sale
