6-S concentrating shaking table for sale with reasonable price
Shaking table , ore shaking table is one of the main mineral processing equipment; it is widely used in sorting tungsten, tin, tantalum and niobium and other rare metals and precious metal ores. It can also be used for sorting iron, manganese ore stone and coal. When dealing with tungsten, tin and other minerals, its effective recovery size is 2-0.02 mm.
1. shaking table application:
The large range of transverse slope adjustment(0~10°),adjustable stroke;
Keep the stably operation when change the transverse slope and stroke
Spring is arranged in the case with compact structure
Without reagents consumption, little electricity consumption
3. Working principle of shaking table :
The working principle of gold concentrating table is to use the combined action of the specific gravity difference of sorted minerals, alternating movement of bed surface, and transverse oblique water flow and riffle (or notch groove), to allow loose layering of ores on the bed surface and fan-shaped zoning. Then different products concentrate,middle ores and tailings can be produced.
4. shaking table main technical parameters:
Item | LS<6-s> | Ys |
Bed structure | Polyester glass steel , embedded skeletons composite structure | Polyester glass steel. embedded skeletons composite structure |
Bed specification | 150-1850x4500mm | 150-1850x4500mm |
Sorting area | 7.5m2 | 7.5m2 |
Bed direction | The left-right | The left-right |
Landscape angle(°) | 0-5 | 0-5 |
Stroke | 10-30mm | 8-22mm |
Times(times/min) | 240-360 | 240-360 |
Size of material selected | Grit 2-0.5mm,fine sand 0.5-0.074mm,pulp 0.074mm | Grit 2-0.5mm,fine sand 0.5-0.074mm,pulp 0.074mm |
Motor power | 1.1kw | 1.1kw |
5.shaking table structure:
