0.35 Cubic meters small flotation machine for mineral ore beneficiation plant
- 40 Set / Sets per Month
- Qingdao Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Hot sale best price metal ore crusher,metal ore crusher with CE
- Hot Selling jaw stone crusher jaw grinder and crusher manufacturer
- Hot Selling jaw stone crusher jaw crusher capacity 110-250tons congo
- Hot sale New type sand making plant in india for sale with low price
- High quality crushed stone processing and pulverized mineral processing
- Zenith construction sand making plant,construction sand making plant price
Product Details
Condition: | New | Type: | Flotation Separator | Production Capacity: | see the table |
Place of Origin: | Henan, China | Brand Name: | Lanji | Model Number: | SF series and XJK series |
Voltage: | 380V | Power(W): | refer to specification | Dimension(L*W*H): | according to models |
Weight: | refer to specification | Certification: | ISO9001:2008 | Warranty: | 1year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
0.35 Cubic meters small flotation machine for mineral ore beneficiation plant :
Flotation machine is widely applicable for coarese separation, fine separator and reverse flotation of nonferrous metals like copper, lead, zinc,nickel and molybdenum
1. Application of Flotation Machine:
SF Flotation Machine is applicable for separating non-ferrous metal, black metal, noble metal, non-metal mineral, raw body and materials of chemical industry, which are subject to coarse separation, swept separation, fine separation and floatation, so the useful ore are reclaimed.the flotation machine will add chemicals to achieve the flotation separating efficiency.
2. The main features of Flotation Machine:
Compared to ordinary flotator, the SF Flotation Machine has the following advantages:
(1)Improve quality grade up to 4-6%
(2)Improve the recovery rate up to 8%
(3)Improve yield up to 12%
3.Flotation machine main structure:
4.Flotation machine working principle:
The impeller is rotated by V-belt of motor and produces negative pressure by centrifugal function. Enough air is sucked to mix slurry, and slurry mixes drug at the same time. Mineral sticks on bubble completely and floats on the surface of slurry to form mineralized bubble. Useful bubble is scraped out by adjusting flashboard height and controlling liquid surface.
5. Main technical parameters for flotation machine:
Model | XJK-0.35 (3A) | XJK-0.62 (4A) | XJK-1.1 (5A) | XJK-2.8 (6A) | XJK-5.8 (7A) | ||
Effective cubage(m 3 ) | 0.35 | 0.62 | 1.1 | 2.8 | 5.8 | ||
Production capacity(m 3 /min) | 0.18-0.4 | 0.3-0.9 | 0.6-1.6 | 1.5-3.5 | 3-7 | ||
Rotation speed(r/min) | 470 | 400 | 330 | 280 | 240 | ||
Blade diameter(mm) | 300 | 350 | 500 | 600 | 750 | ||
Motor | Model | Rotor | Y90L-4 | Y100L2-4 | Y132M2-6 | Y160L-6 | Y200L2-6 (Y225M-6) |
Scraping plate | Y90S-4 | Y90S-4 | Y90S-4 | Y90S-4 | Y90L-4 | ||
Power (kw) | Blade Motor | 1.5 | 3 | 5.5 | 11 | 22(30) | |
Scraping plate Motor | 1.1 | 1.1 | 1.1 | 1.1 | 1.5 | ||
Weight(t/single trough) | 0.43 | 0.86 | 1.38 | 2.33 | 3.533 |
SF series flotation machine :
Model | SF0.37 | SF0.7 | SF1.2 | SF2.8 | SF4 | SF8 | |
Trough capacity(m²) | 0.37 | 0.7 | 1.2 | 2.8 | 4 | 8 | |
Blade diameter(mm) | 300 | 350 | 450 | 550 | 650 | 760 | |
Production capacity(m²/min) | 0.2-0.4 | 0.3-0.9 | 0.6-1.2 | 1.5-3.5 | 0.5-4 | 4-8 | |
Blade rotation speed(r/min) | 352 | 400 | 312 | 268 | 238 | 191 | |
Motor |
Model | Y90L-4 | Y100L-4 | Y132M-6 | Y160L-6 | Y180L-6 | Y250M-8 |
Y90S-4 | Y90S-4 | Y90S-4 | Y90S-4 | Y90L-4 | Y100L-6 | ||
Power(kw) | 1.5 | 3 | 5.5 | 11 | 15 | 30 | |
1.1 | 1.1 | 1.1 | 1.1 | 1.5 | 1.5 | ||
Dimension(mm) | 700×700×750 | 900×820×950 | 1100×1100×1100 | 1700×1600×1150 | 1850×2050×1200 | 200×2900×1400 | |
Single trough weight | 468 | 600 | 1373 | 2338 | 2660 | 4130 |
Contact: Ms Sara Mobile phone(whatsapp): 008613783471727 skype(wechat): sarapang6
