Long working life aac block making plant with ISO certificate
- 50 Set / Sets per Month
- Shanghai Tianjin
- T/T L/C D/P D/A
- Hand press block making machine QTJ4-50
- Pioneer high capacity AAC Block Production Line
- China pe200x300 smallest jaw crusher
- XIEXING XQY2000 Hydraulic pressure molding machine for sale
- High Capacity Clay Brick Making Machines With 20stripe/M 18.8kw Power CE / ISO Certificate
- High Speed Clay Brick Cutting Making Machine 12000kg With 36000pcs/Hr Capacity
Product Details
Condition: | New | Type: | Other, light weight brick, AAC block making machine | Brick Raw Material: | Fly Ash |
Processing: | Brick Production Line | Method: | Hydraulic Pressure | Automatic: | Yes |
Capacity: | 30,000 m³ to 200,000 m³ per year | Place of Origin: | Henan, China | Brand Name: | Lanji |
Model Number: | customization | Voltage: | 380v | Power: | 300-900 |
Dimension(L*W*H): | 30*12*8m | Certification: | ISO9001 | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Long working life aac block making plant with ISO certificate
Autoclave aerated concrete block machine:
AAC Machine is horizontally set, the cover is made of a 16mnr steel plate, the flanges used in the cover and body of the machine is forged from a 16mn steel bar. Strict non-destructive Testing and heat treatment should be performed to the welding lines in the pressure sustaining parts according to relevant specifications.
Features:
1 .Product weight is according to 600 kg/m3 to control.
2 .Annual capacity 200,000M3.
3 . Set raw material proportion: cement 6.5%, raw lime 23%, fly ash 68%, gypsum 3%, aluminum paste powder 350g/M3.
4 .Water and material rate 0.631
5 .One mould product 2.88M3
6 .Casting slurry cycle time 5-6 minutes, cut cycle time 5 minutes.
7.Casting slurry temperature 38-42 degree
8 . body quiet stop. Time is 1.5-2.5housr, temperature 50-90 degree, after quiet stop body strength is 0.15-0.18Mpa
9 .Steam curing cycle time, come in and out autoclave about 0.5hour, steam curing cycle time about is 6 hours/1.6Mpa, total 6.5 hours.
Specification:
Cement lime fly ash style aerated block raw material proportion
name | unit | Cement lime fly ash |
flash | % | 65-70 |
cement | % | 6-15 |
lime | % | 18-25 |
gypsum | % | 3-5 |
Aluminum powder paste(600kg/m3) | 1/10000 | 8 |
Water & material rate |
| 0.60-0.65 |
Casting system | OC | 36-40 |
Aluminum mixing time | S | 30-40 |
11. Cement lime Sand style aerated block raw material proportion
Name | Unit | Cement Lime Sand |
Sand | % | 55-65 |
Cement | % | 10-20 |
Lime | % | 20-30 |
Gypsum | % | 2-3 |
Aluminum powder paste(600kg/m3) | 1/10000 | 8 |
Water & material rate |
| 0.65-0.75 |
Casting system | OC | 35-38 |
Aluminum mixing time | S | 30-40 |
Our factory is professional manufacturer of autoclaved aerated concrete (AAC) plants for more than 10 years, and we can supply complete set of autoclaved aerated concrete plant withcapacity of 50 000m³, 100 000 m³, 150 000 m³, 200 000 m³, 250 000 m³, 300 000 m³annually, including plant design, equipments installation, technical support, personal training, etc, and also can design and manufacture as per clients' requirement and so on.
Raw materials: cement, lime, sand (or fly ash), gypsum, aluminum powder, water.
