Asphalt Spraying Truck/Distributor
Mass parameter | ||||
Kerb Weight(kg) | 4985 | Total Weight(kg) | 8495 | |
Rated loading Weight(kg) | 3315 | Dimension(mm) | 7380×2250×2650 | |
Chassis Parameter: | ||||
Chassis Model | HFC1081KT | Tyre Model | 7.50-16 | |
Wheelbase (mm) | 3308 | Max. Power(kw) | 80 | |
Engine model | CY4102-C3D | Displacement(ml) | 3856 | |
Spray specification: | ||||
Tank Capacity(L) | 5000 | Spray width | 6000mm | |
Hydraulic pump model | CBQ-F540 | Spray Value | 0.5-3.0(Kg) | |
Hydraulic motor | L2F63W2P2 (Liyuan Brand) | Insulation Thickness | 50mm | |
Controller | ZM-5 | Nozzles | 39 | |
Burner | G20(Riello) | Asphalt pump | CB450 | |
Generator(Converter) | YGBT2500 | Emission Standard | GB17691-2001(Ⅱ) GB3847-1999 | |
Best Services Just For You!!
We are 5 years gold supplier on Alibaba.
Click the Link to our homepage.
The extremely considerate and sincerely service would be provided to our customers immediately in CNCAC once made the order. This including:
1. Operator Training;
2. Spare Parts Supply;
3. Life-long Technical-support;
4. we can supply installation, commissioning, training etc;
5. welcome to visit our factory at any time any where!!!
Hangzhou ICOM construction Machinery Co., Ltd. is a professional manufacturer of asphalt machines. Our sales and R&D team have over 10 years experience to focus on asphalt distributor, synchronous pavement surface vehicles and other road machinery and equipment . Based on innovation and expertise, we have received more than 10 patents, selling more than 20 countries and regions.Focus cast quality, intentions to win the trust. We will offer innovative, professional, practical asphalt machinery and equipment with the spirit of craftsman.
Hangzhou IKOM Construction Machinery Co., Ltd.
Telephone: +86-571-88260773
Fax: +86-571-88492538
