Help CenterZQZ5250GWTB Road Equipment Synchronous Chip Sealer Price
Related Products
-
Stone Chip Sealer Roads for SaleUS$ 100,000 - 150,000MOQ: 1 Set -
Chip Sealer en Mexico Equipment for SaleUS$ 100,000 - 150,000MOQ: 1 Set
-
Howo China Chip Sealer Truck Road Equipment SuppliersUS$ 100,000 - 150,000MOQ: 1 Set
-
Chips Spreader Machine for Road MakingNegotiableMOQ: 1 Piece
-
Asphalt Distributor Trailer Trucks For SaleNegotiableMOQ: 1 Unit
Parameters&Specification( ZQZ5250GWTB Synchronous Chip Sealer)
Mass parameter: | ||||
Kerb Weight(kg) | 15670 | Total Weight(kg) | 25000 | |
Rated loading Weight(kg) | 9200 | Dimension(mm) | 10210×2495 ×3450 | |
Chassis Parameter: | ||||
Chassis Model | SX1255JM434 | Tyre model | 12.00R20 | |
Wheelbase (mm) | 4325+1350 | Tread (mm) | 2035/1800 | |
Front Overhang(mm) | 1525 | Rear Overhang(mm) | 2800 | |
Approach angle,Departure angle | 30°/15° | Minimum Ground Clearance (mm) | 250 | |
Engine parameter: | ||||
Engine model | WP10.270N | Manufacturer | Weichai Power Co. , Ltd | |
Max.Power(kw) | 199 | Max. Torque(N.m) | / | |
Fuel | Diesel | Displacement(ml) | 9726 | |
Chip sealer specification: | ||||
Tank Capacity(m³) | 6 | Chippings Capacity(m³) | 10 | |
Hydraulic pump model | CBQ-F563 | Spray width | 3500mm | |
Hydraulic motoe | L2F63W2P2(LIYUAN) | Spray Value | 0.5-3.0(Kg) | |
Controller | ZM-3D | Insulation Thickness | 50mm | |
Generator(Converter) | YT6800E(YITENG) | Nozzles | 28 | |
Asphalt pump | QGB450(SHANGGUI) | Burner | G20(Riello) | |
Other parameter: | ||||
Max. truck speed(km/h) | 92 | Max. Grade ability | >23% | |
Spring films(Front/Rear) | 9/12 | Minimum turning diameter (m) | 15.4 | |
|
| Axis No. | 3(6*4) | |
This is a new generation of asphalt and stone crushing synchronous seal paver with the latest scientific and technological achievements of ICOM Machinery. The appearance of the synchronous vehicle breaks through that of traditional pavement construction vehicle. Structure and coating are more high-end and practical. The construction operation is more convenient and quick for the construction personnel.
parts( ZQZ5250GWTB Synchronous Chip Sealer)
Working condition ( ZQZ5250GWTB Synchronous Chip Sealer )
About the factory ( ZQZ5250GWTB Synchronous Chip Sealer )
Generally, the Synchronous Chip Sealer are shipped in bulk
Best Services Just For You!!
We are 5 year gold supplier on Alibaba.
Click the Link to our homepage.
The extremely considerate and sincerely service would be provided to our customers immediately in CNCAC once made the order. This including:
1.Operator Training;
2.Spare Parts Supply;
3.Life-long Technical-support;
4. we can supply installation, commissioning, training etc;
5. welcome to visit our factory at any time any where!!!
Hang zhou ICOM Construction Machinery Co., Ltd is located in Hangzhou, it was the branch company of CHINA NATIONAL COMMERCIAL AUTOMOBILE CO.,LTD(CACAC), The CNCAC passed the ISO9001:2008international quality system certification and products 3C authentication, the products cover asphalt distributor, synchronous chip sealer, bitumen equipment, chipping spreader.
1. Methods of Payment:
T/T (Telegraphic Transfer) or Western Union or L/C at sight
2. MOQ:
No requirement for testing and trial order
3. Handling time for an order:
Within 10 days supplied from stock
4. Shipping way:
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
5. Quality Control:
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.
6. After Services:
a. Our sales team will response for your question within 24 hours (Holidays Excluded)
b. Technical Support will be available in any time
c. Free replacement will provide once the failure confirmed caused by our product quality.
