Product Details
Place of Origin: | Zhejiang, China | Brand Name: | CNCAC | Model Number: | ZQZ5311TFC |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Parameters&Specification( ZQZ5311TFC Synchronous Chip Sealer)
Mass parameter: | ||||||
Kerb Weight(kg) | 21200 | Total Weight(kg) | 31000 | |||
Rated loading Weight(kg) | 9670 | Dimension(mm) | 12000×2500 ×3730 | |||
Chassis Parameter: | ||||||
Chassis Model | ZZ1317N4647C | Tyre model | 12.00-20,12.00R20 | |||
Wheelbase (mm) | 1800+4600+1350 | Tread mm | 2022/1830 | |||
Engine parameter: | ||||||
Engine model | WD615.95 | Manufacturer | China Heavy Duty Truck Group Co., Ltd. | |||
Max.Power(kw) | 247 | Max. Torque(N.m) | 1300/1600 | |||
Fuel | Diesel | Displacement(ml) | 9726 | |||
Chip sealer specification: | ||||||
Tank Capacity(m³) | 8 | Spray width | 3800mm | |||
Hydraulic pump model | CBQL-E563 | Spray Value | 0.5-3.0(Kg) | |||
Hydraulic motoe | L2F63W2P2(Liyuan) | Insulation Thickness | 50mm | |||
Controller | ZM-3D | Nozzles | 32 | |||
Generator(Converter) | YT6800T | Burner | G20(Riello) | |||
Asphalt pump | QGB450(Shanggui) | Chipping capacity(m³) | 10m3 | |||
|
|
|
|
Advantages and characterstics( ZQZ5311TFC Synchronous Chip Sealer)
1,Patent “Cuniform” shape stainless steel nozzles assemble can achieve high spray finishing.
2,Stainless steel nozzles are higher anti-abrasion performance than copper nozzles.
3,The use of stainless steel laminar flow theory combination of nozzle design, the smooth asphalt spray fan bifurcation is not easy to reduce asphalt consumption.
4,Innovative oil heating systems to heat-conducting oil heating up faster, especially to heat bitumen pump when using emulsion bitumen.
5,Designed by early shunt method of gravel fabric chute can perform more uniform spreading gravel.
6,Adopt fixed aggregate bin + Movable aggregate bin can increase the capacity of loading aggregate.
7,Asphalt mixing gate is reserved for installation of shaft for easy synchronization converted into rubber asphalt spreaders.
8,Through the precise control of electrical and hydraulic pressure to achieve scratch spray
9,The control system user-friendly interface designed to make operation convenient and friendly.
Best Services Just For You!!
We are 5 year gold supplier on Alibaba.
Click the Link to our homepage.
The extremely considerate and sincerely service would be provided to our customers immediately in CNCAC once made the order. This including:
1.Operator Training;
2.Spare Parts Supply;
3.Life-long Technical-support;
4. we can supply installation, commissioning, training etc;
5. welcome to visit our factory at any time any where!!!
Hangzhou ICOM construction Machinery Co., Ltd. is a professional manufacturer of asphalt machines. Our sales and R&D team have over 10 years experience to focus on asphalt distributor, synchronous pavement surface vehicles and other road machinery and equipment . Based on innovation and expertise, we have received more than 10 patents, selling more than 20 countries and regions.Focus cast quality, intentions to win the trust. We will offer innovative, professional, practical asphalt machinery and equipment with the spirit of craftsman.
1. Methods of Payment:
T/T (Telegraphic Transfer) or Western Union or L/C at sight
2. MOQ:
No requirement for testing and trial order
3. Handling time for an order:
Within 10 days supplied from stock
4. Shipping way:
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
5. Quality Control:
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.
6. After Services:
a. Our sales team will response for your question within 24 hours (Holidays Excluded)
b. Technical Support will be available in any time
c. Free replacement will provide once the failure confirmed caused by our product quality.
