vertical wind turbine generator

Specifications

vertical wind turbine generator
direct drive,no noise
lower start wind speed
higher wind coefficient
CE,ISO9001

vertical wind turbine generator









Material introduction:



wind turbine blades: We utilize high strength glass fibre reinforced plastic and epoxy resin to make blades.The wind rotor operate well(stably and quietly).This kind of new aerofoil is elaborately designed by aerodynamic and hydromechanical specialists(experts).It start-up wind speed(or cut-in wind speed)is very low,and the wind energy (rotor power)coefficient is very high.

Generator:It is made up of the superior high strength permanent magnetic material.The volume is small and the weight is light, the generating electricity coefficient is high.The generator specialist(expert) use special electromagnetic technology to make the generator have extremely low start-up drag torque, which can make sure the VAWT start-up in the gentle breeze.The generating electricity coefficient, start-up performance and overspeed overload capacity of generator are all in leading position in this field.

Whole machine:It is made up of steel precision casting.It is widely used in air temperature:-30°C-60°C,high humidity, karaburan and salt mist(in some atrocious weather).It has high reliability.BF series small VAWT,whose appearance is beautiful,installation is easy.You can enjoy the clean (green)energy,at the same time,you will see a beautiful scenery.

Power(w)	300	Rated wind speed (m/s)	8-10
Rotor diameter (m)	1.2	Start-up wind speed (m/s)	1.8
Height of blade (m)	1.4	Range of working wind speed(m/s)	1.8-25
Material of blades and numbers	Glass Fiber Reinforced Plastic/5	Survival wind speed (m/s)	50
Rated rotor speed (m/s)	180r/min	Output Voltage	AC24V
Speed regulation method	Electromagnetic control	Stop method	Electromagnetic brake
Wind energy utilized   coeffeicent	30%-40%	Sweep wind area	1.1304 sq.m
Range of working temperature	-45°C-60°C	Suggested supporting battery	2pcs12v100ah
Top weight (kg)	50	Tower type and height	Guy cable tower/6-8m
