Product introduction
With years’ accumulation of experience in R&D, the HCH Ultra-fine Mill is a new ultra-fine pulverizing equipment designed by Hongcheng. This mill is widely used to grind any non-metal minerals with Mohs hardness below 7 and moisture below 6%, such as talc, calcite, calciumcarbonate, dolomite, bentonite, kaolin, graphite, carbon black, etc. This kind of mill is especially suitable for ultra-fine grinding.
HCH Ultra-fine Mill features in space-saving, completeness, wide usage, easy operation, smooth performance, high performance-cost ratio, high efficiency.
Working Principles of HongCheng HCH Super-micro Grinding Mill :
Firstly, raw material is crushed by jaw crusher to the required size, which is lifted up to the hopper. Secondly, the raw material goes into the grinding chamber through the electro-magnetic vibrating feeder at an even rate. Thirdly, the raw material lifted by the shovel is ground into powder between the ring and roller. Fourthly, the powder is blown up to the cyclone collector through the classifier, which will be collected through the discharging valve. The unneeded powder, which cannot go through the classifier, will be reground into the needed powder.
Advantages of HongCheng HCH Super-micro Grinding Mill :
1) The only professional producer of Raymond Mill in China.
2) Powder-saving and Higher Production Capacity (1-40T/H)
3) Smooth and Reliable Performance.
4) Fineness: 100—800 Mesh (Adjustable)
5) Run for 1000 hours without Lubrication
Technical Data of HongCheng HCH Super-micro Grinding Mill :
Model | 2R2713 | 3R3220 | 4R3216/3218 | 5R4119/4121 | |
Roller | No. of Roller | 2 | 3 | 4 | 5 |
Diameter: (mm) | 270 | 320 | 320 | 410 | |
Height: (mm) | 130 | 200 | 160/180 | 190/210 | |
Ring | Inner Diameter: (mm) | 780 | 970 | 970 | 127 0 |
Height: (mm) | 130 | 200 | 160 | 190 | |
Max. Feeding Size (mm) | ≤15 | ≤20 | ≤20 | ≤25 | |
Fineness(mm) | 0.044-0.125 | 0.044-0.125 | 0.044-0.125 | 0.044-0.125 | |
Total Power (kw) | 42.5 | 87.5 | 87.5 | 172.5 | |
Capacity: (t/h) | 0.3-3 | 1-4.5 | 1-4.5 | 2-9 | |
Overall Dimension (L×W×H)(mm) | 5490×3875×5530 | 7464×5000×8345 | 7464×5000×8345 | 11345×6885×10330 | |
Weight: (t) | 5.5 | 14 | 14.2 | 28 | |
Model | HC1000 | HC1300 | HC1460 | HC1700 | HC2000 | |
Roller | Number of Rollers | 3 | 4 | 4 | 5 | 5 |
Diameter(mm) | 320 | 410 | 460 | 510 | 620 | |
Height(mm) | 200 | 230 | 250 | 250 | 250 | |
Ring | Inner Diameter(mm) | 970 | 1270 | 1460 | 1700 | 2000 |
Height(mm) | 200 | 210 | 250 | 250 | 250 | |
Max. Feeding Size(mm) | ≤20 | ≤25 | ≤35 | ≤50 | ≤50 | |
Fineness(mm) | 0.015-0.18 | 0.044-0.18 | 0.022-0.18 | 0.022-0.18 | 0.022-0.18 | |
Total Power(kw) | 105 | 183.5/198.5 | 242 | 364 | 670 | |
Capacity(t/h) | 1.5-6 | 3-12 | 5-15 | 6-25 | 20-45 | |
Weight(t) | 14 | 28 | 37 | 46 | 102 | |
Our service
‘Survival Rests on Quality, Service is the Source of Development’ is what we consistently live up to. Customer’s satisfaction is the momentum and foundation of our innovation. The high operation efficiency of the machines lies on the technical support of pre-sales and technical service after-sales. Hongcheng has a rich experienced, high technology service team with extensive sales-service network to provide our customers the most enthusiasm service and strong technical support worldwide.
Why choose us?
Guilin Hongcheng Mining Equipment Manufacture Co., Ltd. is a leading enterprise of powder processing equipment in China, is a professional supplier of powder processing integrated solution. Depending on the producing and researching experiences for decades, Guilin Hongcheng is able to offer high capacity, high efficiency, low cost and low pollution powder processing equipment for all of our customers.
At present, Hongcheng is entitled to a high fame in powder processing field. Our vision is to establish a global brand for China, we are holding the principle of Quality is the basement of survival, service is the source of development. The equipment and service of Guilin Hongcheng have been spread to Vietnam, Laos, Malaysia, Indonesia, Sultan, South Africa, Russia, Philippines, and, will be in your enterprise.
Contact us
If you are interested in our equipment, please send us an e-mail with the following table. Please tell us the information below so we can offer you a whole set of solution:
- The input material size and moisture.
- The output fineness size.
- The capacity per hour.
- Your contact information (phone number, e-mail address or both).
Please contact us with the following table, thank you!
↓↓↓
