Help CenterProfessional Raymond Roller Powder Mill Machine for Sale of China Supplier
Related Products
-
Hongcheng High Efficiency HLM Cement Vertical Mill for Cement Production LineUS$ 9,999 - 999,999MOQ: 1 Set -
High Efficiency Vertical Roller Mill Cement Manufacturing Equipment and Production LineUS$ 9,999 - 999,999MOQ: 1 Set
-
Hongcheng HLM High Efficiency Cement Grinding Mill / Concrete Production Line / Cement Production Line / Cement PlantUS$ 9,999 - 999,999MOQ: 1 Set
-
China Supplier Building Material / Powder Making Machine / Concrete Powder / Cement Powder / Price ListUS$ 9,999 - 999,999MOQ: 1 Set
-
Eco-friendly Dust-free Calcite / Bauxite / Coal / Petrol Coke / Gypsum / Slag Powder Making Raymond Mill Grinder MachineUS$ 10,000 - 600,000MOQ: 1 Set
Raymond Mill/Grinding Mill/Ultrafine Mill---China No.1 +2000 Case Plants in China
Application of Raymond Powder Mill:
HC-series Grinding Mill is a kind of newly-designed roller-type mill, featuring in higher efficiency, lower power consumption and much better performance than traditional raymond mill. This mill is widely used to grind any non-metallic minerals with Mohs hardness below 7 and moisture below 6%, such as limestone, calcite, activated carbon, talc, dolomite, titanium dioxide, quartz, bauxite, marble, feldspar, barite, fluorite, gypsum, ilmenite, phosphorite, clay, graphite, kaolin, diabase, gangue, wollastonite, quick lime, silicon carbide,bentonite, manganese. The fineness can be adjusted from 0.18mm(80 mesh) to 0.022mm(600 mesh), whose range is much wider than that of traditional raymond mill.
Working Principles of Raymond Powder Mill :
Firstly, raw material is crushed by jaw crusher to the required size, which is lifted up to the hopper. Secondly, the raw material goes into the grinding chamber through the electro-magnetic vibrating feeder at an even rate. Thirdly, the raw material lifted by the shovel is ground into powder between the ring and roller. Fourthly, the powder is blown up to the cyclone collector through the classifier, which will be collected through the discharging valve. The unneeded powder, which cannot go through the classifier, will be reground into the needed powder.
Advantages of Raymond Powder Mill :
- Reliable Performance
(New Technology) new spider-arm and parallel grinding system with advanced and reasonable structure.Lowest vibration and noise, smooth operation and reliable performance. Social and economic benefits have been achieved after this kind of mill was put into market.
- High Efficiency and Lower Power Consumption
Compared with the traditional raymond mill, more raw material can be ground between the roller and the ring per unit time. And the production capacity is 40% higher than that of traditional raymond mill with the same power consumption. 30% power can be saved for producing one ton powder.
- Vibration Absorption System
The vibration absorption system is optional for much finer powder grinding, which can absorb the vibration and make the mill run smoothly and durably.
Technical Data of Raymond Powder Mill :
Model |
2R2713 |
3R3220 |
4R3216/3218 |
5R4119/4121 |
|
|
Roller |
No. of Roller |
2 |
3 |
4 |
5 |
Diameter: (mm) |
270 |
320 |
320 |
410 |
|
Height: (mm) |
130 |
200 |
160/180 |
190/210 |
|
Ring |
Inner Diameter: (mm) |
780 |
970 |
970 |
127 0 |
Height: (mm) |
130 |
200 |
160 |
190 |
|
Max. Feeding Size (mm) |
≤15 |
≤20 |
≤20 |
≤25 |
|
Fineness(mm) |
0.044-0.125 |
0.044-0.125 |
0.044-0.125 |
0.044-0.125 |
|
Total Power (kw) |
42.5 |
87.5 |
87.5 |
172.5 |
|
Capacity: (t/h) |
0.3-3 |
1-4.5 |
1-4.5 |
2-9 |
|
|
Overall Dimension (L×W×H)(mm) |
5490×3875×5530 |
7464×5000×8345 |
7464×5000×8345 |
11345×6885×10330 |
|
Weight: (t) |
5.5 |
14 |
14.2 |
28 |
|
Model |
HC1000 |
HC1300 |
HC1460 |
HC1700 |
HC2000 |
|
|
Roller |
Number of Rollers |
3 |
4 |
4 |
5 |
5 |
Diameter(mm) |
320 |
410 |
460 |
510 |
620 |
|
Height(mm) |
200 |
230 |
250 |
250 |
250 |
|
Ring |
Inner Diameter(mm) |
970 |
1270 |
1460 |
1700 |
2000 |
Height(mm) |
200 |
210 |
250 |
250 |
250 |
|
Max. Feeding Size(mm) |
≤20 |
≤25 |
≤35 |
≤50 |
≤50 |
|
Fineness(mm) |
0.015-0.18 |
0.044-0.18 |
0.022-0.18 |
0.022-0.18 |
0.022-0.18 |
|
Total Power(kw) |
105 |
183.5/198.5 |
242 |
364 |
670 |
|
Capacity(t/h) |
1.5-6 |
3-12 |
5-15 |
6-25 |
20-45 |
|
Weight(t) |
14 |
28 |
37 |
46 |
102 |
|
Send Inquiry to This Supplier
