China supplier Sinking fish food making machine
- 999 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A
You May Like
Product Details
Condition | New | Place of Origin | Shandong, China | |
Brand Name | DATONG | Model Number | SLG | |
Application | Other, Fish, Livestock Farm | Voltage | 380V 440V 220V | |
Power(W) | 80kw | Weight | 1500kg | |
Dimension(L*W*H) | 25000*1500*2200 | Certification | CE ISO9001 | |
Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
China supplier Sinking fish food making machine
Our sample:
2.Raw Material of China supplier Sinking fish food making machine
Corn flour,wheat flour,low temperature,soya flakes meal,rice ,wheat bran,annexing agent,etc.
3.Voltage in China of China supplier Sinking fish food making machine:
Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries
4.China supplier Sinking fish food making machine Process chart:
Blender→elevator→Storage→Conditioner→Steam Fish food extruder→Air conveyer→Steam Dryer→Hoister→oil sprayer→Double Drum→Cooling conveyer→Sifter→Packing Machine.
Double screw extruder:
1.The main extruder motor,cutting motor adopts frequency speed controlling with high automation and stable per-formation.we can adjust the motor speec according to our require easily, it can meet human safe level.
2. The screws are made of the alloy steel and special craft, durable usage, high pressure, the screw life is longer,adopt 38CrMnAl.the screw can used long time.
3. This extruder have forced lubrication system, so that it can guarantee the equipment gear transmission and cooling the bearing
4.Auto-temperature control system make the temperature controlling more direct viewing and the parameter more precise.
5.This extruder have Self-cleaning, when stopping, it can be cleaned without disassembling.No need to take out the twin screw to clean it.
6.SLG Series Double screw Extruder is mainly composed by the following parts,evry part paly different role:
Fish food dryer(electricity,gas,steam types)
1. This dryer has the compact structure, small occupying, large drying area, small surface area, slight radiating heat and high thermal efficiency.
2.The belt and the heat preservation use the stainless steel; it is suitable for food safe industry level.
3.The running speed of belt net can be controlled (frequency controlling system)
4.The temperature can be controlled willfully and designed according to the need.
Screw material:
Nitriding treatment(120 Hours)
Depth of Nitrided Layer: 0.5-0.8 mm
Hardness of Nitrided Layer: 950-1100Hv (HRC56°-65°)
Chrome Plating
Thickness of Hard Chrome Plating Layer: 0.05-0.10mm
Hardness of Hard Chrome Plating Layer: ≥950HV
Bimetallic Screw: Plasma Alloy Coating Spraying
Depth of Bimetallic Layer: >2mm
Hardness of Bimetallic Layer: HRC55°-68° Bimetallic Barrel/Cylinder: Centrifugal Casting (Inlay Alloy)
Depth of Bimetallic Layer: >2mm Hardness of Bimetallic Layer: HRC55°-68°
Flavouring System.
Our flavouring system have three kinds of motel.it is double drum sigle drum and octagonal drum
Single drum
Octagonal drum
Cooling system:
Name: Cooling Conveyor
Brand: Datong
Original: China
It is full set stainless steel.The height of the hoister can be adjusted based on the requirement.
Jinan Datong Machinery Co., Ltd is a professional food machinery manufacturer in Jinan city shandong province China.Our company congregates an exceptional food machine engineering team, personal customer service center and highquality manufacturing capabilities have evolved exponentially,We are working hard on explore constantly not only in the research of extrusion technology, but also in food technics to benefit our clients producing newfangled food in their markets. It making us become one of the preeminent providers of reliable extrusion equipment world-wide.
1. Free consultation service before, during, and after sales;
2. Free Project planning and design services upon clients' special demands;
3. Debugging and inspecting of equipment until everything is functional before leaving the factory;
4. Overseas installation and training of equipment maintenance and operating personally;
5. Provide basic production techniques and formulas;
6. 1 year complete warranty for Extruded Food Wheat Corn Snack Pellet Making Machine.
Packing: inside plastic bag, outside wooden case for core filling snack food puffed food making machine (Based on the customers' need adopt the wooden case or wooden pellets, etc.).
Transportation: shipping, train, express or upon clients' demands.
Q: what is the Advantage of the floating fish food making machine
A: 2 years warranty
Quick delivery and offer free extra mould when delivery
Long service life on the operation of our manual brochure
Q: How to place order for the floating fish food making machine
A: you can directly order it online via Trade Assurance, we will receive your order and response you at once; After you confirm the suitable machine and deposit us via Trade Assurance, we will arrange the cargo timely and efficiently;
Q: Do you accept OEM special orders?
A: OEM special order is also available because we have our own factory, which is a leading manufacturer in this area with 15 years' experience;
Q: What is the real delivery time of your factory?
A: 5 to 7 days for general series products, meanwhile, batches products & customized products would need 30 days to 60 days based on different conditions;
Q: How do you ensure the quality of your floating fish food making machine?
A: Generally, our equipments are the most durable type our customers at home or abroad. With our experienced quality control team, we are trying to offer you the product with best quality. However, we do recognize that there do have small amount of the product which may got faulty or damaged for different reasons
