9FQ series tangential feed spice hammer mill
Description
A spice hammer mill is a machine used to shred or crush spices into smaller pieces. The basic design of machines of this type involves a rotating shaft to which free-swinging hammers are attached. This assembly is enclosed by a drum which holds the material to be pulverized.
A hopper feeds the source material into the drum. The hammers gradually break up the material until it is small enough to pass through a screen with openings corresponding to the desired particle size.
Features
1.Compact design with high production efficiency, easy operation and maintenance;
2.Quenched manganese steel hammers with hardness HRC56-62 ,shows excellent wear-resistance;
3.Upper and lower housing made from cast iron or 4mm thick steel plate for long service life;
4.Different mesh screens available
5.Electric motor or diesel powered
Application
Hammer mill is widely uesd in livestock farm, feed processing plant, Ethanol plant and many industries to grind:
1. Roughages
stalks of rice, wheat, corn, sorghum, oat and bean
vine and stem of tuber crops
corn cobs
husks and shells
hay
2. Concentrates such as grains and kernels
3.Others:
Coal
Biomass & Biofuels
Crab, Clam & Oyster Shells
Salt Cake
Spice
Waste papers and more...
Why PTO hammer mill?
A power take-off (PTO) is any of several methods for taking power from a power source, such as a running engine, and transmitting it to an application such as an attached implement or separate machines.
Voltage in countries differ from one another, or not accessible for some regions. spice hammer mill can be driven by a electric motor or a diesel for your choice.
Particle Size Refference
Parameter
Model | Weight (KG) | Dimension (MM) | Match Power | Hammer Qty | Screen Mesh (MM) | |
(KW) | (HP) | |||||
9FQ36 | 85 | 900*750*1070 | 5.5-7.5 | 10 | 12 | 0.5-5 |
9FQ40 | 160 | 945*835*768 | 7.5-11 | 12 | 12 | 1.2-8 |
9FQ42 | 125 | 730*650*920 | 11-15 | 18 | 16 | 1.2-20 |
9FQ50 | 280 | 1150*1200*1090 | 11-15 | 20-28 | 16 | 1.2-20 |
9FQ50-40 | 275 | 1100*930*1030 | 22-37 |
| 24 | 1.2-30 |
9FQ50-50 | 360 | 1157*1250*1030 | 30-37 |
| 30 | 1.2-30 |
9FQ50-60 | 380 | 1157*1355*1030 | 37-45 |
| 36 | 1.2-30 |
9FQ-SS | 100 | 850×630×800 | 2.2 |
| 12 | 0.5-5 |
Model | Rotor Dia. (mm) | Main Shaft Speed (r/min) | Feeding Method | Hammer Position* (mm) |
Hammer Width (mm) | Hammer Arrangement |
9FQ36 | 360 | 4600 | tangential | 10 | 200 | interlaced |
9FQ40 | 400 | 4000 | 12 | 200 | ||
9FQ42 | 420 | 3200 | 5-8 | 275 | ||
9FQ50 | 500 | 3300 | 12 | 267 | ||
9FQ50-40 | 500 | 3400 | 6-15 | 396 | ||
9FQ50-50 | 500 | 3400 | 7-19 | 497 | ||
9FQ50-60 | 500 | 3400 | 7-19 | 597 |
