Home > Products > biomass burner > Replace Coal Fired Boiler Biomass Pellet Burner
Replace Coal Fired Boiler Biomass Pellet Burner
- 100 Set / Sets per Month
- QINGDAO
- T/T L/C D/P D/A Credit Card PayPal
- Full automatic energy saver 450000kcal Biomass pellet burner for fuel oil burner
- Energy-efficiency industrial biomass wood pellet burner
- Wood Pellet Biomass Burner/ Biomass Gasifier for Connecting Boiler
- Wood Pellets Burner Connect Wood Stoves/ Wood Boilers
- China supplier pellet burners home / wood pellets burner
- New Machines Power Saver Pellets Burner
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | RotexMaster |
Model Number: | YGF-30 | Voltage: | 220V 380V 450V 600V | Power(W): | 0.75kw |
Weight: | 0.7T | Dimension(L*W*H): | 1920*925*1750mm | Certification: | CE,BV,SGS |
Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
seaworthy package
Product Description
Replace Coal Fired Boiler Biomass Pellet Burner
Pellet Burner Description:
Pellet Burner is the equipment of changing forest waste, scraps into high quality
fuel gas, no harmful emission, protects the limited fossil resources, use the
renewable energy enough, in line with the world, especially the energy conservation
and emission reduction national conditions of our developing country.
The Model of Biomass Burner
Model | Calorific value (kilocalorie) | Power (Kw) | Consumption of fuel(Kg) | Weight (T) | Dimension (mm) | Equipment protection way |
YGF20 | 20 | 0.75 | 50 | 0.6 | 1900*910*1710 | air-cooled |
YGF30 | 30 | 0.75 | 75 | 0.7 | 1920*925*1750 | |
YGF45 | 45 | 1.12 | 115 | 1 | 1830*1100*2130 | |
YGS/F60 | 60 | 1.9 | 150 | 1.6 | 2340*980*2180 | water-cooled |
YGS90 | 90 | 3.1 | 225 | 2.2 | 2340*980*2180 | |
YGS120 | 120 | 3.7 | 300 | 3 | 2790*1190*2400 | |
YGS180 | 180 | 5.25 | 450 | 3.8 | 2900*1300*2400 | |
YGS240 | 240 | 8.45 | 600 | 4.8 | 3180*1490*2400 | |
YGS300 | 300 | 10.45 | 750 | 8 | 3800*1950*3130 | |
YGS360 | 360 | 10.45 | 900 | 9 | 3950*2100*3270 |
Wide application of Pellet Burner
pellet burner is suitable for steam boiler, fuel oil, gas, coal boiler, various kinds of
organic spray drying equipments, large-scale farming factories, cereal and food
drying, tobacco drying, various kinds of large, medium, small workshops,
greenhouse heating and etc.
Details of the burner
1,burner mouth :connect with boiler or dryer. according to the size of your boiler,
then design the burner mouth for you.
2,water inlet. Cool water can enter into the water interlayer from here. This is
water cooling system, thus can reduce the temperature of burner.
3,water outlet.hot water can be come out from the water outlet.
4,air increasing fan, there are two air increasing fans in it. One of them for burner
mouth, and anther one is for bottom of burner. for sufficient burning.
5,igniting hole, for ignite the biomass burner automaticly.,
6,ash discharge hole , for cleaning some times.
7,view hole, we can watch the flame situation the fire of burn.
8,feed inlet connect with pipe, so the material be entered into from here.
9,diesel igniter for ignite biomass burner.
Some details of the burner
Save for you(1000kg/h steam boiler)
Boiler equipments | Material consumption | Unit price of fuel | Operation cost |
Light diesel oil boiler | 66Kg | 1USD/KG | 69.3USD |
Heavy oil boiler | 70Kg | 0.75USD/KG | 52.5USD |
Natural gas boiler | 79.3Nm | 0.58USD/KG | 46.3USD |
Electricity boiler | 720Kw | 0.2USD/KG | 144USD |
Biomass burner | 145Kg | 0.16USD/KG | 24.2USD |
Fuel coal boiler can recovery cost within 2- 3months ,
Fuel oil (natural gas) boiler can recovery cost within 20-30days.
Fuel coal boiler can save energy 30%-40%.
Fuel oil(natural gas)boiler can save energy 50%-70%
We can also provide you various types different capacities wood pellet machines:
Contact
Skype:3085457114(at)
Tele/fax:+86-0531-18615687606
Tradmanager:cn1513371974
Whatsapp:+86-0531-18615687606
Shandong Rotex Machinery Co.,Ltd is an enterprise of research and development,
manufacturing, international trade as a whole, registered capacity is 10 million
Yuan, more than 150 staff. Strong technical force, advanced production technology,
perfect after-sales service.
Mainly produce: biomass fuel pellet production line, feed pellet production line,
organic fertilizer and Municipal Solid Waste processing equipment, agricultural
equipment, forestry equipment, etc.
1.Technical guidance, according to your capacity and raw material ,recommend a
suitable model;
2.Visit to our factory and have an investigation and performance test;
3.Engineers available to service machinery overseas;
4.Warranty 1 year,quality guarantee except wear parts and wrong operation.
Company Profile
Shandong Rotex Machinery.,Co.Ltd, Which located in Jinan , Capital of Shandong Province, Zibo east, its north and south bordering 309 State Line and Jinan-Qing dao High Speed, just 30kilometers away from Jinan International Airport. The company is a collection of research, development,production , operating as one of modern machinery manufacturing enterprises, Registered capacital of 10 million, employs more than 150 people, strong technical force, advanced production technology, perfect after-sales services .
We are doing biomass fuel machinery, fodder farming ma,chinery, and supporting the auxiliary equipment of drying, cooling,dust removal equipment and other machinery products, the main products:Flat Die Pellet Machine , Ring Die Wood Pellet Machine , Drum Wood Chipper and Hammer Mill two series ; Air Flow, Rotary Dryer ,Cooling Equipment and other two series of Screener, Belt Conveyors and other equipments .
Our Company has ISO9001-2000 Certification,CE Certification,SGS Certification etc.Products cover the enviromental carbon, biomass,urban and rural environment,culture and other fields.There are five main series: the biomass compression molding equipment, garbage disposal equipment for urban and rural ,organic fertilizer equipment and environment, Feeder Equipment and Environmental protection equipment .
We are an enterprise of science and technology , which combined the scientific researchand development, manufacturing and training , international trade.Especially in the energy shorttage today , starting from customers'interests, standing in the perspective of customers , considering for our customers, with our professional knowledge, designing more reasonable manufacturing flow and produceing much better products .
Companies adhere to the "Service, Quality First, Brand, Reputation First" Principle to provide our customers with the best quality services .Welcome the customers to visit to our factory.
