widely used belt conveyor hot sale

Specifications

used belt conveyor
1.CE&ISO certificate
2.capacity40-1284t/h
3.speed1.3-2.0m/s
4.back lighted inspection

widely used belt conveyor hot sale





I. Belt conveyor introduction:

Belt Conveyor is a kind of machine that to transfer the material continuously. The belt works under the effect of frictional force. It is not only the components to transfer the material, but also the components to transfer the force. The Belt Conveyor is advanced and simple in structure, easy to maintain. Its transfer capacity is high, transfer distance is long



II. Belt conveyor application:

Belt conveyor is the essential and economical transferring set in the uninterrupted production line. In terms of transferring capacity, belt conveyor can be classified into two types, the heavy type such as for mining convey and the light type for plastic, food and chemical industry, etc. Belt conveyor features with strong transferring capacity, easy maintenance and long conveying distance. The conveyors consist of standard parts, which are advanced and simple in structure, easy to maintain. Our vibrating equipment is adaptable for stationary and mobile crushing plants.



III. Accessory of belt conveyor:



  •1. The conveying quantity is worked out by the following conditions: material density is between 1.0t/m3-1.6t/m3; conveyor obliquity is less than 18o and the material stockpile angle is 30o.

  •2. Density of material is less than 2.5t/m3.

  •3. The conveying length is not restricted to the form; different length can be manufactured according to customers’ demands.



IV. The benefits of belt conveyors:



  ♦1. The smooth, continuous surface of a conveyor belt is ideal for many product handling applications. Some of the benefits of belt conveyors include:

  ♦2. Small or delicate part handling

  ♦3. Accumulation

  ♦4. Inclining and elevating with high friction or cleat belts

  ♦5. Clean room environments

  ♦6. Small parts transfer

  ♦7. Back lighted inspection

  ♦8. Quiet operation



V. Belt conveyor parameters:

Belt width ( mm )	Convey length (m)  /  power (KW)			Speed(M/S)	Capacity(t/h)
400	≤12 / 1.5	12-20 / 2.2-4	20-25 / 3.5-7.5	1.3-1.6	40-80
500	≤12 / 3	12-20 /4-5.5	20-30 / 5.5-7.5	1.3-1.6	78-191
650	≤12 / 4	12-20 / 5.5	20-30 / 7.5-11	1.3.-16	131-323
800	≤6 / 4	6-15 /5.5	15-30 /7.5-15	1.3-1.6	278-546
1000	≤10 / 5.5	10-20 / 7.5-11	20-40 / 11-12	1.3-2.0	435-853
1200	≤10 / 7.5	10-20 /11	20-40 / 15-30	1.3-2.0	655-1284
