Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher

Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher thumbnail-1
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher thumbnail-2
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher thumbnail-3
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher thumbnail-4
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher thumbnail-5
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher thumbnail-6
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher photo-1
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher photo-2
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher photo-3
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher photo-4
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher photo-5
Industrial High Efficiency 1.5kw 15kw 30kw Hot Sale to India Mobile Jaw Crusher photo-6
US$ 2,000 - 99,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Jaw Crusher
Application:
crusing, Ore industry
Contact Supplier Request Quote Chat Now
Henan Yuhui Mining Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianijin Shanghai Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Jaw Crusher
Application crusing, Ore industry
Motor Type AC Motor
Power(W) according the model
Capacity(t/h) various
Place of Origin Henan, China
Brand Name Yuhui
Model Number many tyoes
Dimension(L*W*H) according to the model
Weight according o the model
Certification ISO1900:2000
Warranty 1YEAR, One year
After-sales Service Provided Engineers available to service machinery overseas

Industrial high efficiency 1.5kw 15kw 30kw hot sale to India mobile  jaw crusher

Industrial high efficiency 1.5kw 15kw 30kw hot sale to India mobile jaw crusher

1.Brief introduction of jaw crusher:
Jaw Crusher is one of main equipment of stone crushing is ideally suitable for crushing all kinds of ores and crushing the big size materials, the highest anti-pressure strength of crushed material is 320 MPA, having two types: primary crushing and secondary crushing. Jaw crusher has been sold to 75 countries, the price and quality of jaw crusher is widely recognized, we always stick to be your satisfying partner.
2.Features of PE series jaw crusher:
  PE series jaw crusher has big reduction ratio, equal product granularity, low power consumption and convenient maintenance. It is perfect equipment for crushing ores and rocks in medium and small mine, metallurgy, building materials, chemical industry.

3.Working principle:
  Motor drives belt and belt pulley, makes moving jaw up and down through eccentric shaft. When the moving jaw is up, the angle between lining plate and moving jaw becomes large, and this will push moving jaw plate close to the fixed jaw plate. During this process, the material is crushed and ground, thus the crushing will be done. When the moving jaw is down, the angle between lining plate and moving jaw becomes small, the moving jaw plate will leave the fixed jaw plate on account of the effect of pulling bar and spring, and then the crushed material will be discharged from the lower opening of the crushing room. With the motor continuously rotating and the material periodically crushed and discharged by the crusher, the mass production can be realized.



4. main Technical Parameters of  stone jaw crusher

Model

Feed Opening
(mm)

Max. Feed Size
(mm)

Capacity
(t/h)

Power
Consumption
(kw)

Discharge Opening
(mm)

Overall Dimension
(L x W x H)
(mm)

PE-150×250

150×250

125

1-5

5.5

10-40

758×758×794

PE-250×400

250×400

210

5-20

15

20-60

1500×1400×900

PE-400×600

400×600

340

16-65

30

40-100

1700×1800×1600

PE-500×750

500×750

425

50-100

55

50-100

1890×1940×1870

PE-600×900

600×900

500

50-120

55

65-160

2395×1843×2230

PE-750 ×1060

750×1060

630

52-180

110

80-140

2775×2426×2840

PE-800×1060

800×1060

640

136-230

110

100-200

2500×2472×2810

PE-900×1200

900×1200

750

140-260

110

95-165

3400×3200×3500

PE-1000×1200

1000×1200

850

315-342

110

195-265

3335×3182×3430

PE-1200×1500

1200×1500

1020

400-800

160

150-300

4200×3732×4620

PE-250 ×750

250×750

210

15-30

22

15-70

1400×1300×1350

PE-250×1000

250×1000

210

16-52

30

25-60

1600×2000×1500

PE-250 ×1200

250×1200

210

20-60

37

25-60

1900×2200×1500

PE-300×1300

300×1300

260

30-70

55

30-90

1800×2300×1700

Industrial high efficiency 1.5kw 15kw 30kw hot sale to India mobile jaw crusher
