Industail Big Crushing Ration Coal Jaw Crusher Manufacturer of China

Industail Big Crushing Ration Coal Jaw Crusher Manufacturer of China thumbnail-1
Industail Big Crushing Ration Coal Jaw Crusher Manufacturer of China photo-1
US$ 1,689 - 98,360 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Jaw Crusher
Application:
crushing stones, Mining
Contact Supplier Request Quote Chat Now
Henan Yuhui Mining Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Shanghai Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Jaw Crusher
Application crushing stones, Mining
Motor Type AC Motor
Power(W) many types
Capacity(t/h) 1-800
Place of Origin Henan, China
Brand Name yuhui
Model Number many types
Dimension(L*W*H) many types
Weight many types
Certification ISO, BV
Warranty 12 months, One year
After-sales Service Provided Engineers available to service machinery overseas

Industrial big crushing ration coal jaw crusher manufacturer of China



China high capacity professional jaw crusher
Specification

Size of Feed

 Opening (mm)

Max. Feeding

 Size (mm)

Adjustable Size

 of Discharge

Opening (mm)

Capacity

 (t/h)

Motor Power

 Pole

Power

 (kw)

Dimension Weight
(mm) (t)
PE-150×250150×25012510-401-345.5670×820×7600.81
PE-150×750150×75012510-405-164151050×1490×10553.8
PE-250×400250×40021020-605-204151160×1300×12402.8
PE-400×600400×60035040-10016-656301480×1710×16467
PE-500×750500×75042550-10045-1006551800×1796×194012
PE-600×900600×90050065-16060-1606752235×2210×238017
PE-750×1060750×106063080-14090-32081102430×2302×311029
PE-800×1060300×130064080-200110-35081302530×2310×311030
PE-900×1200900×120075095-165140-45081303789×2826×302550
PE-1000×12001000×1200850110-235160-55081603889×2826×302557
PE-1200×15001200×15001020150-300400-80081204590×3342×3553100.9
PEX-250×750250×75021025-6015-306221750×1500×14205
PEX-250×1000250×100021025-6016-526301940×1650×14507
PEX-250×1200250×120021025-6020-656371940×1850×14507.7
PEX-300×1300300×130025025-10020-906552285×2000×172011
Features of PE series jaw crusher:

          PE series jaw crusher has big reduction ratio, equal product granularity, low power consumption and

convenient maintenance. It is perfect equipment for crushing ores and rocks in medium and small mine,

metallurgy, building materials,chemical industry.

Working principle of jaw crusher:

            The machine’s leather belt and wheel are driven by the electric motor, then the movable jaw begins

to move up and down by the eccentric shaft, when the movable jaw moves from top to bottom, the angle

between fixed jaw and moveable jaw becomes smaller, the movable jaw and moveable jaw deviates from

the fixed jaw plate under the function of dragging rod and spring. At this moment, the crushed materials are

discharged from the bottom outlet of the crushing cavity.





        Established in the 1970s, Henan Yuhui Mining Machinery Co., Ltd. has developed into a famous manufacturer through

40 years' struggling and progressing, specialized in producing mineral dressing equipment, compound fertilizer equipment,

cement equipment, as well as sand making equipment.







A Company You Can Trust:

        Henan Yuhui Mining Machinery Co, Ltd. is located in Zhengzhou City in central plains, which adjoins to ancient millennium

Shaolin Temple (Kongfu Origin) to the south, and Yellow River to the north. With Lianhuo highway and Longhai railway, it owns

convenient transportation and pleasant scenery.

Quality and Safety:

         Our company is devoted to providing advanced and economical technical devices with modern enterprise management

 mechanism, first-class processing equipment, perfect test means, high quality research experts and high quality follow-up

services. Our company has been honored as "Advanced Quality Management Corporation" and "high Reputation Corporation".

 Our products have been selected as "premium brand" products.

Q1.Is your company a manufacturing company and do you have a company certificate?

A: Yes, our company is a manufacturing company and we are specialized in mining machine for more than 40 years with two

factories. Our company has owned the certificate of ISO9001:2000.



Q2. Where are your products mainly exported?

A: Our products are distributed throughout the world, being involved in more than Asia, Africa and South America countries and

regions. And our products win the good reputation of our foreign customers.



Q3. What’s the additional features of your company?

A: We have our own laboratory in the company, so the clients can take some samples to perform experiments on the spot. And

 our engineers will provide the best advice and choice for our clients.



Q4. Welcome to our company:

A: We have stone production line, sand-making production line and so on. The clients can visit our production site.



Q5. How do you guarantee your after service?

A: Our company guarantees repair, replacement and refund and it is warrantable to the complete machine for 12 months. And

we can design the site for free and provide basic materials, assembly drawings and equipment installation technical services.

At the same time, we provide a connected sequence services with directing civil engineering on spot, installing and debugging

the equipment, training technical and operating people broad. Also, our engineers are assured be sent to work broad for a long

 period. Our company supplies accessories for a long period, and lifetime warranty
