Specifications
2012 new high tech jaw crusher series on sale1. flexible payment terms
2. exported to 120 countries
3. quality is prior
2012 new high tech jaw crusher series on sale
1. Working principle of jaw crusher series:
The motor drives the belt wheel, and makes movable jaw up and down by eccentric shaft. When the movable jaw rises, the angle between the fixed jaw and movable jaw gets larger, and the materials can be crushed to reach the crushing target. When the movable jaw is down, the angle between the fixed jaw and movable jaw becomes smaller. The movable jaw plate leaves the fixed jaw plate under the function of drawbar and spring, and then the crushed materials are discharged from the lower outlet of the crushing cavity.
2.Features of jaw crusher:
The jaw crusher is based on a revolutionary modular, non-welded frame construction, offering owners the highest possible fatigue strength, excellent reliability and numerous mounting possibilities. Thanks to the accurately balanced structure, the jaw crusher is one of the most easiest and economical crusher machine to install.
Combined with special high-quality cast steel components and durable wear parts, means exceptionally high crusher availability, cost-efficient crushing and low cost per ton. In all, SBM jaw crusher has simple structure, which bring about easy maintenance; stable performance; even final particles and high crushing ratio.
3. Main technical parameters:
Model |
Feed Opening |
Max Feed Size |
Adjustable Range |
Capacity |
Power |
Weight |
Overall Dimension |
PE-150×250 |
150×250 |
125 |
10-40 |
1-5 |
5.5 |
0.81 |
875×758×850 |
PE-250×400 |
250×400 |
210 |
20-60 |
5-20 |
15 |
2.8 |
1450×1315×1296 |
PE-400×600 |
400×600 |
340 |
40-100 |
25-65 |
30 |
6.5 |
1565×1732×1586 |
PE-500×750 |
500×750 |
425 |
50-100 |
45-80 |
55 |
10.1 |
1890×1916×1870 |
PE-600×900 |
600×900 |
500 |
65-160 |
70-120 |
55-75 |
15.5 |
2305×1840×2298 |
PE-750×1060 |
750×1060 |
630 |
80-140 |
130-260 |
110 |
28 |
2450×2472×2840 |
PE-900×1200 |
900×1200 |
750 |
95-165 |
220-380 |
110-132 |
50 |
3335×3182×3025 |
PE-1000×1200 |
1000×1200 |
850 |
195-265 |
230-380 |
132 |
57 |
3435×3182×3028 |
PE-1200×1500 |
1200×1500 |
1020 |
150-300 |
400-800 |
160-220 |
100.9 |
4200×3750×3820 |
PEX-250×1000 |
250×1000 |
210 |
25-60 |
16-52 |
30-37 |
6.5 |
1530×1992×1380 |
PEX-250×1200 |
250×1200 |
210 |
25-60 |
20-60 |
37-45 |
7.7 |
1900×2192×1430 |
PEX-300×1300 |
300×1300 |
250 |
25-105 |
20-90 |
55-75 |
11 |
2720×1950×1600 |
...
