Specifications
6000t/d clinker rotary kiln for dry process1. dry or wet process
2. fastest delivery
3. flexible payment terms
6000t/d clinker rotary kiln for dry process
1. clinker rotary kiln working principle:
The clinker rotary kiln is a cylindrical vessel, inclined slightly to the horizontal, which is rotated slowly about its axis. The material to be processed is fed into the upper end of the cylinder. As the kiln rotates, material gradually moves down towards the lower end, and may undergo a certain amount of stirring and mixing. Hot gases pass along the kiln, sometimes in the same direction as the process material (co-current), but usually in the opposite direction (counter-current). The hot gases may be generated in an external furnace, or may be generated by a flame inside the kiln
2. clinker rotary kiln features:
1. Catch wheel : mechanical wheel and hydraulic pressure
2.Gearing: single driver or double driver. Control the revolution by YZD, DC motor and
frequency variable motor. Be reliable , energy-saving, and efficient.
3. Cylinder tyre bolster: bolster has three types: fixed type, adjustable type and floating type.
4.The structure is simple,maintenance and replacement are convenient without hurting the cylinder.
3. clinker rotary kiln application:
Rotary kiln is the rotary calcining kiln, which belongs to the building material equipments. According to the material processing, Rotary Kiln can be divided into cement, metallurgical and chemical kiln as well as limestone kiln.
4. main technical parameters:
Model | Technical parameters | Main motor | Main Reductor | Catch wheel | Bearing quantity | Weight(t) | |||||
Speed(r/min) | Obliquity(%) | Capacity(t/h) | Model | Power | Sped | Model | Speed ratio | ||||
Φ1.2×35 | 0.5-1.6 | 3 |
| JZTY71-4 | 22 | 1200/120 | PM650 | 40.17 | machine | 3 | 34 |
Φ1.9/1.6×36 | 0.53-1.59 | 4 | 2.5-3 | JZT-72-4 | 30 | 1200/400 | JZQ750-I | 48.85 | machine | 3 | 53 |
Φ2.1/1.8×36 | 0.5-1.51 | 4 | 4 | JZS-81 | 30/10 | 1410/470 | UT2-110 | 163.36 | machine | 3 | 75 |
Φ2.5×50 | 0.516-1.549 | 3.5 | 5.5 | YCT355-4A | 55 | 1320/140 | ZS165-7 | 99.96 | machine | 3 | 167.5 |
Φ3×48 | 0.3309-3.309 | 3.5 | 35 | ZSN4-250-21B | 90 | 1000/100 | ZI130-14 | 32.11 | machine | 3 | 237 |
