Specifications
sand dryer1.CE&ISO certificate
2.fine workmanship
3.high capacity
4.reasonable structure
2.2*25m indirect heat transfer sand dryer
I. Features of heat transfer sand dryer :
The heat transfer sand drier has advantages of reasonable structure, high efficiency, low energy consumption and convenient for transportation.
II. Composition of heat transfer sand dryer :
The heat transfer sand drier is formed by rotary body, lifting blade, driving device, supporting device and sealing ring.
III. Application of heat transfer sand dryer :
The heat transfer sand drier supplied by Henan Yuhui is widely used in building materials, metallurgy, chemical industry, cement plant for drying of limestone slag, coal powder, slag, clay stone. It can be used for drying many kinds of materials and with convenient and reliable operation, therefore, it has been widely used.
IV. Technical Parameters of heat transfer sand dryer :
Shell diameter×shell length | Inside diameter of outer shell(mm) | Inside diameter of inner shell(mm) | Shell length(mm) | Obliquity | Feeding plate form | Max intake air temperature(°C) | Dimension(m) |
1.515 | 1500 | 500 | 15 | 3-5% | Lifting form | 850 | 16.2×2.7×2.7 |
1.517 | 17 | 18.2×2.7×2.7 | |||||
1.519 | 19 | 20.0×2.9×2.9 | |||||
1.821 | 1800 | 650 | 21 | 3-5% | Lifting form | 850 | 22.5×2.7×2.7 |
1.823 | 23 | 24.5×2.9×2.9 | |||||
1.825 | 25 | 26.5×2.9×2.9 | |||||
2.221 | 2200 | 800 | 21 | 3-5% | Lifting form | 850 |
|
2.223 | 23 |
| |||||
2.225 | 25 |
|
