High Efficient Mill Ball From China Mainland

High Efficient Mill Ball From China Mainland thumbnail-1
High Efficient Mill Ball From China Mainland thumbnail-2
High Efficient Mill Ball From China Mainland photo-1
High Efficient Mill Ball From China Mainland photo-2
US$ 7,548 - 204,918 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Ball Mill
Product Type:
Other
Contact Supplier Request Quote Chat Now
Henan Yuhui Mining Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Dalian Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Ball Mill
Product Type Other
Place of Origin Henan, China
Brand Name Yuhui
Model Number many types
Voltage 380V or as ordered
Power(W) many models
Dimension(L*W*H) many models
Weight many models
Certification ISO, BV
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

high efficient mill ball from china mainland







mill ball application:

  1. widely used in production lines for powders such as including cement, silicates, refractory material, fertilizer, glass ceramics, etc. as well as for ore dressing of both ferrous non-ferrous metals.

mill ball features:



  1. the hollow axis adopts the cast steel and the lining can replace, the rotating big gear processes in the way of casting rolling gear
  2. the barrel body is wearable well and bears wearable scaleboard
  3. the machine run steadily and work reliably
  4. big crushing ratio, uniform final product size
  5. low operating cost

mill ball  working principle:



  1. ball mill is a horizontal rotating device by outer gear
  2. the materials are transferred to the grinding chamber through the quill shaft uniformly
  3. the centrifugal force caused by rotation of barrel brings the steel balls to a certain height

and impact and grind the materials

4.  the materials are discharged through the discharging board then grinding process is finished.



mill ball main technical parameters:



Model

Feeding size(mm)

Discharging size(mm)

Weight of ball(t)

Rotational speed (r/min)

Power(kw)

Capacity(t/h)

Weight(t)

Φ900*1800

≤20

0.075-0.89

1.4

42

18.5

0.65-2

3.6

Φ900*2100

≤15

0.075-0.83

1.7

41

15

0.7-3.5

3.9

Φ900*3000

≤20

0.075-0.89

2.5

41

22

1.1-3.5

4.5

Φ1200*2400

≤25

0.075-0.6

3.5

36

30

1.5-4.7

11.5

Φ1200*2800

≤25

0.075-0.6

4.5

36

37

1.5-5

13

Φ1200*4500

≤25

0.075-0.4

5.5

32

55

1.6-5.8

13.8

Φ1500*3000

≤25

0.047-0.4

8.68

31

75

2-7

17

Φ1500*3500

≤25

0.047-0.4

7.75-6.4

31

75

3-8.5

17.5

Φ1500*4500

≤25

0.047-0.4

10.5

27

110

3.5-8

21

Φ1500*5700

≤25

0.047-0.4

15

27

130

3.5-10

24.7

Φ1830*3000

≤25

0.047-0.4

18

26

160

4-12

28

Φ1800*3600

≤25

0.047-0.4

10.6-11.35

26

160

5-13

33.5

Φ1830*4500

≤25

0.047-0.6

12

26.5

185

5.5-20

35

Φ1830*7000

≤25

0.047-0.4

25

26

210

6.5-22

36

Φ2100*3600

≤25

0.047-0.4

14-15.2

24

185

15-30

46.8

Φ2200*5500

≤25

0.047-0.4

30

21

245

10-20

48.5

Φ2200*6500

≤25

0.047-0.4

31

21

380

14-50

52.8

Φ2200*7500

≤25

0.047-0.4

33

21

380

16-50

56

Φ2400*3000

≤25

0.047-0.4

15.5-16.6

20.6

245

15-55

59







Note: This specification is just reference, any changes are subject to the products.
