Water Purifying Machines / Activated Carbon Filter Sand Filter

Principle
For use of water, coconut shell activated carbon (in the iodine adsorption value of 1000 mg/g or more effective adsorption capacity effectively adsorbed organic matter in raw water, free residual chlorine, colloid, particles, microorganism, some metal ions and decolorating, discharge residual chlorine content < 0.1 mg/L .

Use
Water and food industry, chemical industry, electric power and other industrial water purification, dechlorination, oil removal and to smell, etc

Manual valve model, name list (the valve location see below)

Run, cleaning methods and steps
When the normal operation of the RO system start switch selector switch 】 in 【 operation manual cleaning: general every 48 hours running system will start switch 】 【 RO system selector switch is in "cleaning" position, 10 minutes to wash, manual switch valve is flush for 10 minutes, wash effect is a standard with the water outlet of the clear. (Open valve close attention on after off first!)

Recommended washing cycle: 1/48 hours

Suggested replacement cycle: in order to ensure the normal filtration and adsorption effect of replacement of a filter material every year.

Activated carbon Filter principle

Activated carbon removal of impurity content in water, is based on the activity of activated carbon surface and unsaturated bonds.

Because OF the surface area of activated carbon is very big (500-1500 m2 g). Combined with the surface was covered with an average diameter of 2-3 nm porous, so that activated carbon with high adsorption capacity.

At the same time, because of activated carbon on the surface of the carbon atoms are not equivalent in energy, these atoms containing unsaturated bond, so it is with foreign molecules or groups in the trend of chemical action, strong adsorption ability to deal with some organic compounds.

Studies have demonstrated that activated carbon adsorption of chloride, is not all its surface to physical adsorption of chloride, but because of the activated carbon surface played a catalytic role, prompted the hydrolysis of free chlorine, and generate new ecological accelerated the process of oxygen. The reaction is as follows:

Cl2 + H2O ═ HCL + HCLO

Activated carbon

HCLO HCL + [O]

(The new ecological oxygen)

Here [O] can be produced and easy oxidation of carbon or other component interactions of activated carbon to remove:

C + 2 [O] CO2

Packing:the seller packs all of the machine and parts in the firm case that suitable for sea shipping.
Delivery date:20-30 working day after receive the deposit.

Q:Are you manufacture or trading company?
A:We are factory, we have our own design team and own workshop.

Q:What kind of payment terms do we accept?
A:50%T/T as advance payment,50% before shipment.we also accept Western Union and Money Gram.

Q:How much is the transportation freight?
A:The freight depends on the quantity, weight and size ,also the destination port.

Q:How about the working life of machine?
A:Our machine can be used for over 5 years.

Q:How can I trust your company and ensure to get the goods if order from you?
A:We are Alibaba legitimate certification company(VIP).

Q:How to ensure that I received the machine undamaged?
A:Our package is standard for shipping .

Q:What's your delivery time?
A:20-30 working days according to your quantity.

Q:Can I have my own customized product?
A:Yes, your customized requirements for logo, design and mark etc.are very welcome.

Q:Do you provide installation & debugging service?
A:Yeah,we will send you the installation drawing and documents first, if you still have problems, we will arrange our engineers go to your place for installation guiding.

Factory
We have own factory and skilled workers,rich-experienced design team and good after service. We are a professional sales team with high efficiency, and endeavoring to provide satisfactory services to every of our customers as always.

Quality and Price
Our good quality is built on superior material, imported from Japan, French and so on.We pass ISO9001,CE, GMP. Our price is based on the quality,we give the reasonable price to every customer!

Product  range
We can provide various kinds of stainless products for your choice.Also,we can customize according to   your specific requirements.

Service
1,We have professional engineers and high-quality sales team who are good at English to ensure zero communication barriers to you .

2,Any damage or shortage of our goods when you receive your items, please take some photos for a witness.We will deal with it in 24 hours.

3,If the machine broken in 1 year (from you buy the machine that day ), we will offer the repair.

4,We offer the video to you  teach you how to use ,fix ,maintain this machine.

5,When the machine broken suddenly ,We offer the instruction teach you how to deal with the emergency.
