2015 XG-Q Pneumatic Perfume Capping Machine
Specifications
1.pneumatic preesure 0.4-0.6MPa
2.cap closing with good sealing
3.pneumatic control
4.mould changed
5.Height adjustable
This machine adopts pneumatic control, particularly suitable for glass bottles product bundling.
The company is a design of bundling machine design philosophy is: use special material with oral, put good spray glass bottle into the rolling head, through a balanced pressure nozzle and glass bottles sealed.
The company can be based on customer requirements, through the actual test, to achieve the desired binding speed and effect, is an ideal choice models.
Bundling machine working principle is to open the hand valve and gas connection.
Put the spray head glass bottles to tie verbal, pedal pneumatic switch, userise tops, the bottle is straight, while the cylinder downwardly to tighten ties tightened with oral, oral, cylinder automatic back to the original starting point, completed a Cizha circulation.
With verbal selection
Model: 15 contraction nozzle size: 13---15
Model: 17 contraction nozzle size: 15.75----16.3
Model: 20 contraction nozzle size: 18.5----19.5
Model: 22 contraction nozzle size: 20.8----21.2
With oral according to head the size order.
With oral regulating method
Loosen tie verbal copper heart positioning screw, rotary copper core moves up and down, the general regulation for the nozzle into the mouth tying slightly below the lower plane 20~30 wire. Specific adjust the position fornozzle vary.
Pneumatic sealer is a perfume perfume filling, sealing part, used for a variety of specifications of perfume bottle valve cover seal. Seal sealing diameter; qualified rate; ninety-nine percent.
Guangzhou Jinfeng Light Industry Machinery Co., Ltd. is a manufacturer that produces cosmetic, pharmaceutical, chemical and dairy equipment. We undertake equipment design, manufacture, installation, maintenance, technical improvement support, technical consultancy and other services. Our main products are vacuum homogeneous emulsifying machines, reverse osmosis water treatment machines, automatic and semi-automatic filling machines and all kinds of stainless steel tanks. All of them are of reliable quality and good effect. We have more than ten years' experience in machinery manufacturing and our products have been entered into domestic and overseas markets. The diverse products with high quality can meet various needs of industries mentioned above.
If you are not satisfied, Don't be disappointed,u can tell us ur request and we will recommend one to u. And also can customized, our engineer can exclusively design for u.Thank u for ur inquiry !
