2015 XG-Q Pneumatic Perfume Capping Machine
Working principle
Bundling machine working principle is to open the hand valve and gas connection.
Put the spray head glass bottles to tie verbal, pedal pneumatic switch, userise tops, the bottle is straight, while
the cylinder down wardly to tighten ties tightened with oral, oral, cylinder automatic back to the original starting point, completed a Cizha circulation.
With verbal selection
Model: 15 contraction nozzle size: 13---15
Model: 17 contraction nozzle size: 15.75----16.3
Model: 20 contraction nozzle size: 18.5----19.5
Model: 22 contraction nozzle size: 20.8----21.2
With oral according to head the size order.
With oral regulating method
Loosen tie verbal copper heart positioning screw, rotary copper core moves up and down, the general regulation
for the nozzle into the mouth tying slightly below the lower plane 20~30 wire. Specific adjust the position for nozzle vary.
Main uses
Pneumatic sealer is a perfume perfume filling, sealing part, used for a variety of specifications of perfume bottle
valve cover seal. Seal sealing diameter; qualified rate; ninety-nine percent.
The use of machine condition
Compressed air pressure: 4~6 kg /cm2
Note: when the bottle back to tie verbal, press the return switch off automatically, the bottle.
Before use, please read
Due to personal safety, improve the production efficiency, the proper use of and maintenance of the machine
please be sure to read the instructions for use!
Safety precautions
The error operation may cause dangerous situation, causing injury or damage!When the machine hand watch
close to the work area, to avoid personal danger!
Non professional and technical personnel, no maintenance and inspection machine,or it may cause damage to
the machine.
Product Show
