2015 JF series Automatic filling and capping machine
1.Filling, driven by cylinder photoelectric induction to the bottle into the automatic
filling.
2.The company produced fully automatic filling machine series are all touch screen
operation, on the basis of the original models on the market increased a lot of
practical function.
3.All parts contacting with materials are the links for quick release type, without
special tools.
The basic configuration
1.The whole stainless steel -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- SU304
2.Material contact part of the stainless steel -- -- -- -- -- -- ----SU304
3.The rest parts material -- -- -- -- -- -- -- -- -- -- hard alumina except
4.Material contact parts (stainless steel) -- -- -- -- -- -- -- -- -- -- --PP
5.Filling master cylinder -- -- -- -- -- -- -- -- -- -- -- ---Shanghai STNC
6.Filling head cylinder -- -- -- -- -- -- -- -- -- -- -- -- - Shanghai STNC
7.PLC control system -- -- -- -- -- -- -- -- -- -- -- --Japan MITSUBISHI
8.OPTO-electronic components -- -- -- -- -- -- -- -- -- - -- -AUTONICS
9.Low voltage electrical appliances -- -- -- -- -- -- -- -- -- Japan OMROM
Supply voltage |
220 v ac |
Pressure |
5-8 kg |
Power |
3 KW |
Gas |
60 LITRES minute |
Filling quantity |
25-150 m |
Filling accuracy |
0.5% |
Filling speed |
20-40 bottles/minutes |
The way to work PLC control multiple components, vacuum suction feeding valve to open, will feed valve closed when playing, filling valve opened at the same time, toachieve the effect of filling, the size of the filling amount through touch screen
man-machine interface operation, equipped with an automatic screw cap, automatic
cover, automatic into the screw cover location, automatic screw cap body will cap
lock. Using shock type cap under way, after filling procedure automatically cap
under pressure.
1.Filling head push down by cylinder filling, filling each cylinder descend to bottle,
when dose can be adjusted.
2.The self-priming absorption material.
3.Have no bottle no filling function.
4.The machine automatically on the plug and screw cap function.
5 Screw cap machine by the photoelectric sensing bottle after bottle drops lifting
cylinder screw cover, tighten self-return after waiting for the next bottle into the
screw cap machine, PLC control the whole process, and the torque can be
adjusted.
Article 6 / whole linear velocity Reaches 30 to 55 bottle/min (50 ml of water, for
example).
7.The 85 mm plastic conveyor belt model, motor for the German JSCC card, power
0.06 KW * 2.
8.Filling accuracy is within 0.5% (based on the maximum number of filling machine)
9.Japan Mitsubishi PLC for.
10.For STNC and JYC pneumatic components brand.
11.Electronic components for Japan OMRON brand.
12.Photoelectric Sensor for Japan ONRON brand.
13.All stainless steel / 304 stainless steel.
Guangzhou Jinfeng Light Industry Machinery Co., Ltd. is a manufacturer that produces cosmetic, pharmaceutical, chemical and dairy equipment. We undertake equipment design, manufacture, installation, maintenance, technical improvement support, technical consultancy and other services. Our main products are vacuum homogeneous emulsifying machines, reverse osmosis water treatment machines, automatic and semi-automatic filling machines and all kinds of stainless steel tanks. All of them are of reliable quality and good effect. We have more than ten years' experience in machinery manufacturing and our products have been entered into domestic and overseas markets. The diverse products with high quality can meet various needs of industries mentioned above.
If you are not satisfied, Don't be disappointed,u can tell us ur request and we will recommend one to u. And also can customized, our engineer can exclusively design for u.Thank u for ur inquiry !
