Help CenterMulti-Function Candy Pouch Packing Machinery With Weigher
Related Products
-
Food Thermoforming Vacuum Packing Machine With Ce CertificationUS$ 40,000 - 40,000MOQ: 1 Piece -
Food Dryer/industrial Food Dryer/food Dryer MachineUS$ 8,000 - 40,000MOQ: 1 Set
-
Frozen French Fries (Fresh and Delicious)US$ 50,000 - 50,000MOQ: 1 Piece
-
Fully Automatic Frozen French Fries PlantUS$ 100,000 - 100,000MOQ: 1 Piece
-
High Speed Automatic Packing MachineUS$ 40,000 - 40,000MOQ: 1 Piece
RL420 Technical parameters:
| Model | RL 420 |
| Bag Sizes | L80~300mm W80~200mm max film roll width 420mm |
| Packing Speed | ≤ 90bags/min (the speed will be variable, depends on the product, packaging material, bag size, and other factors. |
| Electricity | AC220V, 50-60Hz, 3.0KW |
| Compressed air | 6-8kg/m2, 0.2m3/min |
| Total weight | 500kg |
| Outer dimension | L1320×W1050×H1450(+350) mm |
1.2 Main features:
Equipped with safety protection, comply with firm's safety management requires;
Use intelligent temperature controlling machine to have accurate temperature control; ensure the artistic and neat seal;
Use PLC Servo System and pneumatic control system and super touch screen to form the drive control center; maximize the whole machine's control precision, reliability and intelligentized level;
This machine completes the whole packing procedure of measuring, loading materials, bagging, date printing, charging(exhausting) and products transporting automatically as well as counting;
Touch screen can store the technical parameters of various kinds of products, no need to reset while products changing;
Have error indicating system, helping to handle the trouble immediately;
Make block bags and hanging bags according to customers' different requires;
Single-belt transportation, placidly and quickly, small friction, little waste.
Application:
Suitable for packing granulated product and powder product, such as extruded snacks, candy, biscuit, roasted seeds and nuts, granulated sugar, deep-frozen food, milk powder, milk tea, flour, chemical powder, species, sauce and so on.
Technical details
| Head | 10-head |
| Max speed | 70bpm |
| Single weigh range | 10-3,000g |
| Average Accuracy | ±0.1g ~2g |
| Controller | 7" colorful screen ( with Chinese & English language version ) |
| Bucket volume | 1.3L by stepping motor |
| Electricity | AC220V, 50-60Hz, 1.5KW, 8.2A single phase |
| Total weight | 400kg |
| Head | 14-head |
| Max speed | 80bpm |
| Single weigh range | 10-3,000g |
| Average Accuracy | ±0.1g ~2g |
| Controller | 7" colorful screen ( with Chinese & English language version ) |
| Bucket volume | 1.3L by stepping motor |
| Electricity | AC220V, 50-60Hz, 1.1KW, 8.2A single phase |
| Total weight | 450kg |
JINAN DAYI EXTRUSION MACHINERY CO.,LTD (Since 1996)
Add: Shandong Yuanyi Industrial Park, No.36, Wuyingshan North Road, Jinan, China 250032
Tel: 0086-531-88600886
Fax: 0086-531-88615226
Mob / Whatsapp / Wechat : +86 187 6619 7959
