No. |
Commodity |
Qty. |
1 |
RL420 Vertical Packing Machine |
1unit |
2 |
Chinese brand 10-head or 14-head Weigher |
1unit |
3 |
Z-shaped Bucket Elevator |
1unit |
4 |
Platform ( to support weigher ) |
1unit |
5 |
Take-away Conveyor |
1unit |
Mainfeatures:
l Equipped with safety protection, comply with firm's safety management requires;
l Use intelligent temperature controlling machine to have accurate temperature control; ensure the artistic and neat seal;
l Use PLC Servo System and pneumatic control system and super touch screen to form the drive control center; maximize the whole machine's control precision, reliability and intelligentized level;
l This machine completes the whole packing procedure of measuring, loading materials, bagging, date printing, charging(exhausting) and products transporting automatically as well as counting;
l Touch screen can store the technical parameters of various kinds of products, no need to reset while products changing;
l Have error indicating system, helping to handle the trouble immediately;
l Make block bags and hanging bags according to customers' different requires;
l Single-belt transportation, placidly and quickly, small friction, little waste.
Application:
Suitable for packing granulated product and powder product, such as extruded snacks, candy, biscuit, roasted seeds and nuts, granulated sugar, deep-frozen food, milk powder, milk tea, flour, chemical powder, species, sauce and so on.
RL420 Technical parameters:
Model |
RL 420 |
Bag Sizes |
L80~300mm W80~200mm max film roll width 420mm |
Packing Speed |
≤ 90bags/min (the speed will be variable, depends on the product, packaging material, bag size, and other factors. |
Electricity |
AC220V, 50-60Hz, 3.0KW |
Compressed air |
6-8kg/m2, 0.2m3/min |
Total weight |
500kg |
Outer dimension |
L1320×W1050×H1450(+350) mm |
Technical details
Head |
10-head |
Max speed |
70bpm |
Single weigh range |
10-3,000g |
Average Accuracy |
±0.1g ~2g |
Controller |
7” colorful screen ( with Chinese & English language version ) |
Bucket volume |
1.3L by stepping motor |
Electricity |
AC220V, 50-60Hz, 1.5KW, 8.2A single phase |
Total weight |
400kg |
Head |
14-head |
Max speed |
80bpm |
Single weigh range |
10-3,000g |
Average Accuracy |
±0.1g ~2g |
Controller |
7” colorful screen ( with Chinese & English language version ) |
Bucket volume |
1.3L by stepping motor |
Electricity |
AC220V, 50-60Hz, 1.1KW, 8.2A single phase |
Total weight |
450kg |
Technical parameters:
Model |
RT-100 |
Bucket volume |
1.8 L with food sanitation degree |
Discharge height |
3.1-3.2m to the ground |
Top height |
3.6-3.8m to the ground |
Speed |
60 buckets per min with fixed speed |
Electricity |
AC220V single phase or 380V, 3P, 50-60Hz, 1.2KW |
Total weight |
700kg |
Outer dimension |
L3100×W530×H3700mm |
Description :
- Its design is copied from American famous food production manufacturer here , which has higher efficiency, with Z-shaped frame to save lots of space, airproof structure without to touch the normal condition. There`s no materials overflowing between hopper and vibrator . Meanwhile the safety door and hopper door will be fabricated neatly & gracefully ,which improve the working room sanitation conditions, with lower cost.
1. It has single discharges to feed products one station.
2. It`s controlled by cabinet controller with fixed speed
3. The bucket volume is 1.8L with food sanitation degree
4. Adopt the vibration hopper to keep the product without products falling down.
5. It includes the Vibration Feeder & Storage Hopper
JINAN DAYI EXTRUSION MACHINERY CO.,LTD (Since 1996)
Add: Shandong Yuanyi Industrial Park, No.36, Wuyingshan North Road, Jinan, China 250032
Tel: 0086-531-88600886
Fax: 0086-531-88615226
Mob / Whatsapp / Wechat : +86 187 6619 7959
Send Inquiry to This Supplier
