Spiral Salt Washer for Salt Production Line

Spiral Salt Washer for Salt Production Line photo-1
US$ 10,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, spiral salt washer
Product Type:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
Nanjing Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, spiral salt washer
Product Type Other
Place of Origin Jiangsu, China
Brand Name Kingreat
Voltage 110v, 220v, 380v, 440v, 460v
Power(W) 3.7-7.5kw
Dimension(L*W*H) Depend on model choosing
Certification ISO
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Spiral salt washer is one of the equipments of the salt production line. It is used for salt transportation and washing. Salt is spiraldriven for agitated washing and transportation. Wash liquid is sprayed into at the middle of washer for countercurrent washing. Suspending impurities flow out from overflow channel and precipitated impurities is periodically discharged from bottom dirty removing valve. It structure is similar to those of spiral conveyers. It is used for washing up-middle sized salt with better effect being the optimized selection for washing soluble impurities and in-soluble materials.

Technical Parameters
Model
Capacity (t/h)
Power (kw)
Spiral strip diameter (mm)
Inclined angle
LX45
3-5
3.7
480
15
LX62
8-12
5.5
620
15
LX78
14-16
7.5
780
15
Detailed Images
Packing & Delivery
Our Service

1. 12 months guarantee period from machine arriving date.
2. Abundant spare parts in stock are available to provide.
3. Our technicians could be dispatched for overseas service.
4. 7*24 hours technical consultation.
5. Your workers could get trained both in our factory and yours.
6. Routine tracing till the machine work properly will be done timely.
7. We will remind you to do the normal maintenance.
8. Your suggestions or any comments & reflection would be treated in priority.
9. Marketing team will visit you during our visit in your country if you require.
