PNYB High Efficiency Plate Type Hermetic Juice Filter

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai Nanjing Ningbo Zhangjiagang
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, high efficiency plate type hermetic juice filter, plate
Structure	Other, high efficiency plate type hermetic juice filter, filter gauzes lifting	Place of Origin	Jiangsu, China
Brand Name	Kingreat	Model Number	PNYB-2
Weight	300kg	Dimension(LWH)	6206001550mm
Certification	ISO	Warranty	12 months
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

PNYB High Efficiency Plate Type Hermetic Filter, vhigh efficiency plate type hermetic juice filter

PNYB high efficiency plate type hermetic juice filter

Product Overviews

PNYB High Efficiency Plate Type Hermetic Filter is a high-efficient, energy-saving and hermetically operated fine filter equipment. It is widely used in chemical, petroleum, painting, foodstuff, pharmaceutical and many other industries.

The main body of the filter is made up of vessel, filter gauzes lifting structure and automatic discharging device. Filter gauzes are made by material of multilayer stainless steel which installed at center liquid pipe and cleaned up conveniently.

In the process of filtration ,the unfiltered liquid with filter aid come into the body through transmission system(pump or other tools.)After a stable filter cake formed on the filter gauze flakes, the filtrate are filtered through the micropores of filter cake.

Technical parameters

Model	Filters area m²	Filters cake volume L	CapacityT/h			Working pressureMPa		Working temperature	Volume of filtering jar L	weight Kg
Model	Filters area m²	Filters cake volume L	Oil	Resin	Beverage	Rated Pressure	Max Pressure	Working temperature	Volume of filtering jar L	weight Kg
PNYB-2	2	30	0.4-0.6	1-1.5	1-3	0.1-0.4	0.5	≤150	120	300
PNYB-4	4	60	0.5-1.2	2-3	2-5				250	400
PNYB-7	7	105	1-1.8	3-6	4-7				420	600
PNYB-10	10	150	1.6-3	5-8	6-9				800	900
PNYB-12	12	240	2-4	6-9	8-11				1000	1100
PNYB-15	15	300	3-5	7-12	10-13				1300	1300
PNYB-20	20	400	4-6	9-15	12-17				1680	1700
PNYB-25	25	500	5-7	12-19	16-21				1900	2000
PNYB-30	32	600	6-8	14-23	19-25				2300	2500
PNYB-36	36	720	7-9	16-27	13-31				2650	3000
PNYB-40	40	800	8-11	21-34	30-38				2900	3200
PNYB-45	45	900	9-13	24-39	36-44				3200	3500
PNYB-52	52	1040	10-15	27-45	42-51				3800	4000
PNYB-60	60	1200	11-17	30-52	48-60				4500	4500
PNYB-70	70	1400	12-19	36-60	56-68				5800	5500
PNYB-80	80	1600	13-21	40-68	64-78				7200	6000
PNYB-90	90	1800	14-23	43-72	68-82				7700	6500

Pictures

Note: filtering capacity: when oil is treated, it means the filtered volume of oils containing 2-5% of whitish soil. When resin is treated, it means the average filtered volume of alkyd resins fineness of 5-15μm. Filtering capability is in relation to the impurity content of the medium to be filtered.

Factory
