SZL series horizontal paper plate filterSZL Series Horizontal Paper Plate Filter
SZL series horizontal paper plate filter is a solid-liquid separating equipment with characteristics as high-efficiency, energy-saving, hermetic operating. It is widely used in chemical, petroleum, foodstuff, oils and fats, pharmacy, etc.
The filter is composed of tank, layers of horizontal filter plates and filter paper which is installed between filter discs. Filter paper is used as filter medium to pressed filter in middle of two filter plates from hole which are around the filter plates. Filtrate comes into hole of filter plate through filter paper and support plates, and comes out from the bottom after filter finished using compressed air to press the residual liquid out.
This filter is a precision, clarification equipment. We can get filtrate with different precision through choosing filtering paper.
Model | Filter area (m²) | capacity (T/h) | Working pressure (MPa) | Working temperature() | Dia of inlet and outlet (mm) | Dia of filter plate (mm) | Dia of drum (mm) | Overall dimension (Φ×H)(mm) |
SZL-1.5 | 1.5 | 2 | ≤0.3 | ≤150 | DN50 | Φ275 | 400 | 550×975 |
SZL-3 | 3 | 4 | DN50 | Φ533 | 600 | 900×1700 | ||
SZL-5 | 5 | 7 | DN50 | Φ685 | 800 | 1100×1800 | ||
SZL-7 | 7 | 10 | DN50 | Φ685 | 800 | 1100×2050 | ||
SZL-10 | 10 | 13 | DN50 | Φ840 | 900 | 1200×2000 | ||
SZL-12 | 12 | 15 | DN50 | Φ840 | 900 | 1200×2150 |
Note: filtering capacity: when oil is treated, it means the filtered volume of oils containing 2-5% of whitish soil. When resin is treated, it means the average filtered volume of alkyd resins fineness of 5-15μm. Filtering capability is in relation to the impurity content of the medium to be filtered.
