Specifications
plate filterHigh effeciency, large capacity, automatic continuous operation and discharge, fine polished SS, matt,carbon steel
Model NYB High Efficiency Hermetic Plate Filter
NYB High Efficiency Plate Type Hermetic Filter is a high-efficient, energy-saving and hermetically operated fine filter equipment. It is widely used in chemical, petroleum, painting, foodstuff, pharmaceutical and many other industries.
Since this equipment has many advantages such unique structure, compact volume, high filter efficiency, fineness of filtered liquor, no material wastage, quantity of filter aid. It can be conveniently maintained, cleaned and operated at very low cost.
Model | Filtering area (m²) | Filters cake volume (L) | Capacity(T/h) | Working pressure (MPa) | Working temperature (℃) | Volume of filtering jar (L) | Weight (Kg) | |||
Oil | Resin | Beverage | Rated | Max | ||||||
PNYB-2 | 2 | 30 | 0.4-0.6 | 1-1.5 | 1-3 | 0.1-0.4 | 0.5 | ≤150 | 120 | 300 |
PNYB-4 | 4 | 60 | 0.5-1.2 | 2-3 | 2-5 | 250 | 400 | |||
PNYB-7 | 7 | 105 | 1-1.8 | 3-6 | 4-7 | 420 | 600 | |||
PNYB-10 | 10 | 150 | 1.6-3 | 5-8 | 6-9 | 800 | 900 | |||
PNYB-12 | 12 | 240 | 2-4 | 6-9 | 8-11 | 1000 | 1100 | |||
PNYB-15 | 15 | 300 | 3-5 | 7-12 | 10-13 | 1300 | 1300 | |||
PNYB-20 | 20 | 400 | 4-6 | 9-15 | 12-17 | 1680 | 1700 | |||
PNYB-25 | 25 | 500 | 5-7 | 12-19 | 16-21 | 1900 | 2000 | |||
PNYB-30 | 32 | 600 | 6-8 | 14-23 | 19-25 | 2300 | 2500 | |||
PNYB-36 | 36 | 720 | 7-9 | 16-27 | 13-31 | 2650 | 3000 | |||
PNYB-40 | 40 | 800 | 8-11 | 21-34 | 30-38 | 2900 | 3200 | |||
PNYB-45 | 45 | 900 | 9-13 | 24-39 | 36-44 | 3200 | 3500 | |||
PNYB-52 | 52 | 1040 | 10-15 | 27-45 | 42-51 | 3800 | 4000 | |||
PNYB-60 | 60 | 1200 | 11-17 | 30-52 | 48-60 | 4500 | 4500 | |||
PNYB-70 | 70 | 1400 | 12-19 | 36-60 | 56-68 | 5800 | 5500 | |||
PNYB-80 | 80 | 1600 | 13-21 | 40-68 | 64-78 | 7200 | 6000 | |||
PNYB-90 | 90 | 1800 | 14-23 | 43-72 | 68-82 | 7700 | 6500 | |||
Note: filtering capacity: when oil is treated, it means the filtered volume of oils containing 2-5% of whitish soil. When resin is treated, it means the average filtered volume of alkyd resins fineness of 5-15μm. Filtering capability is in relation to the impurity content of the medium to be filtered.
