Continuous Discharging Oil Drilling Machine
Taking advantage of the principle that the light liquid, heavy liquid and solid phase, with different density and mutually insoluble in the mixed liquid, gain different sedimentation speed in the centrifugal force field or gravity force field, separating stratification or causing the solid particles in the liquid to deposit can be achieved.
In the gravity force field or centrifugal force field, the light liquid phase, the heavy liquid phase and the solid phase with different density and mutually insoluble in the mixed liquid, respectively gain different sedimentation speed, and thus separate and stratify. In the gravity force field it is called gravity separation, while in the centrifugal force field it is called centrifugal separation.
Drilling mud is an integral part of most drilling operations,it is also called drilling fluid, there are some solids suspended in the fluid.
Kingreat Decanter Centrifuge can provide solid-liquid separation technology to your drilling mud application, enabling reuse of the material and more efficient and cost-effective disposal.We have our special design and collocation decanter centrifuge for oilfield and industrial solids control, drilling fluid / mud cleaning and process water treatment.
Kingreat Decanter centrifuges are used to process water-based and oil-based drilling fluids. Oilfield decanter centrifuges mechanically increase the gravitational force exerted on the liquid and solids mixture present in the mud system. We can apply over 3,000 G-forces machine to separate the particles in the fluid.
Kingreat Decanter centrifuges have wide process capacity to meet all ranges as per drilling program.It is commonly and widely used used for oilfield and gas well operations providing efficient solids control while significantly reducing the operator's total mud cost and minimize waste disposal volumes.
Model |
Diameter (mm) |
Bowl Speed (rpm) |
Length (mm) |
G-force |
Capacity (m3/h) |
Main motor Power (kw) |
Assistant motor power (kw) |
Weight (kg) |
Overall Size (L × W × H) (mm) |
PNX409 |
250 |
5500 |
850 |
3493 |
0.2-2 |
15 |
4 |
1020 |
2500 × 650 × 760 |
PNX-414 |
355 |
4000 |
860 |
3175 |
1~10 |
18.5 |
7.5 |
2035 |
2765 × 920 × 1060 |
PNX-416 |
355 |
4000 |
1160 |
3175 |
1~15 |
18.5 |
7.5 |
2122 |
3065 × 920 × 1060 |
PNX-418 |
355 |
4000 |
1460 |
3175 |
1~25 |
22 |
7.5 |
2222 |
3365 × 920 × 1060 |
PDC-1655 |
420 |
3000 |
1450 |
2113 |
10~30 |
55 |
15 |
4600 |
4080 ×1100 × 1420 |
PDC-17-4 |
420 |
3600 |
1680 |
3042 |
3~15 |
30 |
7.5 |
5165 |
3331 × 990 × 1066 |
PDC-18-4.4 |
450 |
3300 |
2000 |
2739 |
10~20 |
37 |
11 |
2739 |
4000 × 1120 × 1239 |
PDC-20 |
500 |
3200 |
2000 |
2860 |
5~45 |
55 |
11 |
4400 |
4489 × 1160 × 1350 |
PDC-21 |
540 |
2800 |
2000 |
2366 |
15~50 |
45 |
15 |
5290 |
4587 × 1285 × 1368 |
PDC-24 |
620 |
3200 |
2480 |
3555 |
15~60 |
Hydraulic station 90 |
8000 |
4650 × 2010× 1200 |
|
PDC-28HH |
720 |
2200 |
2400 |
1975 |
15-80 |
110 |
37 |
9393 |
4800 ×1350 × 1500 |
1. Automatic continuous operation
2. Water level adjustable
3. Highest efficiency and lowest power consumption
4. PLC control
5. Screw conveyor full tiled
