Snack Food Drying Oven

Specifications

Snack food drying oven
Application:dry soya nuggets, cereal, snacks etc.
Capacity:100-500kg/h

1. Description     food roasting machine

1. These series of roasting/drying oven are widely used, it is used for drying all kinds of stick, piece, grain etc. shape inflating snack food, the user can choose different types of dryer according to layer, length or energy.
2. The whole machine is compact design, logical and easy operation.
3. Driving system adopts double pitch roller chain driving, circulating drying, and balanced running, never jam.
4. Drying temperature and time can be adjusted, effect of drying is capitally.
5. With high efficiency fuel saving system, reasonable heat distribution, material be heated equally, low energy but large output.
6.  A frequency converter can adjust the drying time for the product speed. Variable speed of the belt is available.
7. Electricity heating is heated by infrared heating pipe by electricity. here is a convenient set for spraying lubricating oil to the bearings.For using gas or diesel oil as energy resource, we use International Brand Burner, BALTUR S.P.A. It is in good quality and safe.

2. Products: This dryer oven can be used to produce soya nuggets, cereal, snacks ect

3. Capacity: 240kg/h, 500kg/h, 1ton/h



4. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries

5. dryer oven materials: All the machines are made by stainless steel



6. Technical Parameters             dryer machine

dryer model	electric(gas/diesel) consumption	heating temperature	output	dimension	applied products
Three-layer electric oven	30kw/h	180°c	150kg/h	5400x1300x2000mm	Puffed snacks, breakfastcereals
Three-layer electric oven(longer)	45kw/h	180°c	250kg/h	7000x1600x2150mm	Puffed snacks, breakfast cereals
Three-layer gas/diesel oven	4.8-10 m³/h(gas) 5.1-10kg/h (diesel)	180°c	150kg/h	6500x1600x2000mm	Puffed snacks,breakfast cereals
Three-layer gas/diesel oven(longer)	16-22 m³/h (gas) 7-14kg/h (diesel)	180°c	250kg/h	8000x1800x2150mm	Puffed snacks, breakfastcereals
Five-layer electric oven	60kw/h	180°c	250kg/h	5800x1300x2400mm	Puffed snacks, breakfastcereals
Five-layer gas/diesel oven	16-22 m³/h (gas ) 7-14kg/h (diesel)	180°c	250kg/h	6000x1500x2400mm	Puffed snacks, breakfastcereals
Seven-layer dryer	48kw/h	90°c	100kg/h	9000x2400x3000mm	extruded pellets
Rotary dryer	45kw/h	180°c	250kg/h	6500x1600x2000mm	Puffed snacks, breakfast cereals

 7. dryer oven Sample Pictures



 8.Production

a.) Design: All the machines are elaborately designed by our mechanical engineers who are rich of experience in this field. We accept special design according to customer’s request.

b.) Processing & Assembling: Parts processing, assembly, testing are based on standard test.

c.) Trial Run: Each machine has to be tested before its deliver.



9. Delivery

The machines is possible to pack in wooden case or nude pack after wraping by plastic film.



 10. Service & Installation

a.) Consultation service before, during, and after sales;

b.) Project planning and design services;

c.) Debugging of equipment until everything is functional;

d.) Management of equipments' long distance shipping from seller's factory to named place by buyer;

e.) Training of equipment maintenance and operating personally;

d.) New production techniques and formulas;

e.) Provide 1 year complete warranty and life-time maintenance service.

11.Certifications to guarantee the quality!



As one of the largest food machine maker in China,we have passed CE, ISO9001, and received many patent

certificates from our government.
