How Dry Pet Food Is Made
While there are numerous ways to make kibble and other dry pet food products, the most commonly used process is extrusion. This process was adapted for making pet food in the 1950s based upon technology used in the production of puffed breakfast cereals.
Making Dry Pet Food by Extrusion
1.Ingredients are brought together in a mixer. Dry ingredients may be ground prior to incorporation
with wet ingredients. Once mixed together, they form a moist dough.
2.The dough is heated in the preconditioner prior to introduction to the extruder.
3.The extruder, similar to a giant meat grinder that is heated, is where the primary cooking phase for dry extruded pet food products occurs. The dough is cooked under intense heat and pressure as it moves toward the open end of the extruder. At the end of the extruder, hot dough passes through a shaping die and knife (similar to the action of a meat grinder) where the small pieces expand rapidly into kibble once they are under standard air pressure.
4.Kibble is dried in an oven until its moisture content is low enough to make it shelf stable like a cookie or cracker.
5.After drying, kibble may pass through a machine that sprays on a coating, which is generally a
flavor enhancer.
6.The oil/fat coating machine is followed by a cooling phase.
7.Packaging (bags, boxes, pouches, etc.) is filled during the last step to precise amounts to meet the weight advertised on the label. The final result is finished pet foods or treats.
c. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to your Local voltage and frequency.
d. Machines Materials:All the machines are made by food grade stainless steel3 04, this line is with reasonable design and with high automation; the screws are made by alloy steel, with building block system structure and self-cleaning function
e. Dry Type Technical Parameters:
Model | Installed power | Real power | Output | Dimension |
DP65-III | 70kw | 40kw | 100-150kg/h | 22000x1200x2200mm |
DP70-II | 90kw | 50kw | 200-240kg/h | 25000x1500x2200mm |
DP85-II | 120kw | 100kw | 400-500kg/h | 30000x3500x4300mm |
f. Wet Type Technical Parameters:
Model | Installed power | Extruder main motor | Output | Dimension |
DP85 | 72kw | 45kw | 0.2-0.4ton/h | 22000x2000x2500mm |
DP90 | 122kw | 55kw-75kw | 0.8-1.2ton/h | 35000x3000x3500mm |
DP95 | 170kw | 90kw-160kw | 2.5-3.0ton/h | 45000x6000x4500mm |
DP130 | 340kw | 190kw-260kw | 3.0-5.0ton/h | 55000x6000x7500mm |
Kind Remind:
If you are interested in our machine, please detail your requirements while you are sending your inquiry, the more, the better, so that we can give you the best recommendation.
We also provide other kind of Pet Food Extruding Line,Pet Treats Extruding Line,Pet Treats Moulding Machine,Pet Biscuit Processing Line,Meat Strip
Forming Machine,Rawhide Bone Pressing Machine...
