High protein high nutrition dog food extrusion machines
1. Description:
Pet food is plant or animal material intended for consumption by dogs or other canines. The pet food is close to the human beings food in the fine level, the health index and the nutritional ingredients, some of them request more highly than human beings.
In extruder, the ingredients are cooked under intense heat and pressure as it moves toward the open end of the extruder where ingredients pass through a shaping die and knife. Dog food is dried in a multi-pass dryer until its moisture content is low enough to make it shelf stable. Dog food may pass through a coating drum where animal fat and vitamins are applied onto dog food.
a. Raw Materials: adopts corn flour, fish meal as raw materials
b. Products: different shapes are made by adjusting the dies from extruder
c. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to your Local voltage and frequency.
d. Machines Materials:All the machines are made by food grade stainless steel304, this line is with reasonable design and with high automation; the screws are made by alloy steel, with building block system structure and self-cleaning function
e. Dry Type Technical Parameters:
Model | Installed power | Real power | Output | Dimension |
DP65-III | 70kw | 40kw | 100-150kg/h | 22000x1200x2200mm |
DP70-II | 90kw | 50kw | 200-240kg/h | 25000x1500x2200mm |
DP85-II | 120kw | 100kw | 400-500kg/h | 30000x3500x4300mm |
f. Wet Type Technical Parameters:
Model | Installed power | Extruder main motor | Output | Dimension |
DP85 | 72kw | 45kw | 0.2-0.4ton/h | 22000x2000x2500mm |
DP90 | 122kw | 55kw-75kw | 0.8-1.2ton/h | 35000x3000x3500mm |
DP95 | 170kw | 90kw-160kw | 1.5-3.0ton/h | 45000x6000x4500mm |
DP130 | 340kw | 190kw-260kw | 3.0-5.0ton/h | 55000x6000x7500mm |
The information listed in this table is subject to change
for machine developing purpose without prior notice.
Capacity of 600-800kgs/hr:
- Commissioning & After-sales Service
1. We make accurate factory layout design according to customer’s factory size; if the customer needed, we could make workshop design with electricity power, water supply, gas power, material storage, final storages, worker’s restroom, etc.
2. After delivering machines to client’s factory, we start to apply for the Visa to client’s country immediately; normally the vessel needs 20-60 days to the required port, so we have enough time to get the Visa. While the machines arrives your factory, our engineers are ready to start for the commissioning service.
3. 1-2 of our engineers will go to your factory to install and adjust the processing line to realize normal production at shortest time.
4. Our engineers have responsibility to train and teach the workers how to operate, clean, maintain and repair all the machines, until the workers could well operate the processing line.
5. It normally costs 10 days for the commissioning service, and we supply 1 year guarantee from the date of completion of commissioning service.
6. The engineer’s round-trip flight tickets, accommodation and daily salary USD 30 are on client’s account.
Kind Remind:
If you are interested in our machine, please detail your requirements while you are sending your inquiry, the more, the better, so that we can give you the best recommendation.
We also provide other kind of Pet Food Extruding Line,Pet Treats Extruding Line,Pet Treats Moulding Machine,Pet Biscuit Processing Line,Meat Strip
Forming Machine,Rawhide Bone Pressing Machine...
Inquiry now!
More than 5 years working experience in food and beverage industry.
Have sold products to 80 countries.
Consider service is the first vital force for an enterprise.
Want to be your friend sincerely.
