Twin Screw Extruder Machine for Pet Dog Food Production Line

Twin Screw Extruder Machine for Pet Dog Food Production Line photo-1
Twin Screw Extruder Machine for Pet Dog Food Production Line photo-2
Twin Screw Extruder Machine for Pet Dog Food Production Line photo-3
Twin Screw Extruder Machine for Pet Dog Food Production Line photo-4
Twin Screw Extruder Machine for Pet Dog Food Production Line photo-5
US$ 7,500 - 160,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Eagle
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name Eagle
Model Number DP65/70/85/90/95
Application Other, Dry pet food
Voltage 380V/50HZ
Power(W) 45-132kw
Weight 1500kg
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description
China Supplier  Dry Pet Food Production Line
Product Description

A. Description:

Twin Screw Extruder for Pet Food's screws are all made by 38CrMoAIA and alloy layer with the hardness of 55hrc, which is hard and strong, and has longer service life (1.5-2 years);

Barrel is divided into 3 parts; the hardness of the barrel is 55hrc.

The barrel and the screws of  Twin Screw Extruder for Pet Food are modular in structure. Each module is equipped with its own thermoregulation ring with cooling circuits and electric heating resistances;

Co-rotating screws with extremely deep profiles to increase mechanical working capacity


B. Raw materials:

Corn flour, wheat flour, Bone meal, fish/Shrimp meal, etc;

C. Products:
Different shapes are made by changing the dies

D. Capacity:
150kg/h, 250kg/h, 500kg/h, 1000kg/hr, 2000kg/hr.

Twin Screw Extruder Machine for Pet Dog Food Production Line

Twin Screw Extruder Machine for Pet Dog Food Production Line
2. Flow chart
Mixing system---Extrusion system----Drying system----Flavoring system

Twin Screw Extruder Machine for Pet Dog Food Production Line

3. Voltage
Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries

Technical Parameters

ModelDP-65DP-70DP-85DP-90
Capacity120-150kg/hr150-300kg/hr500-800kg/hr800-1000kg/hr
Power80kw90kw150kw200kw
Dimension18 x 5 x 3m20 x 5 x 3m35 x 5 x 3m40 x 5 x 3m

Advantage

CE Certified Twin Screw Extruder for Pet Food has stainless steel structure, especially the parts in contacting with the raw material or products

A wide range of products can be obtained in a variety of different ways, and can configure various dies simply and rapidly;

The use of a continuous automatic process provides greater production outputs than offered by traditional systems, with savings in energy and reduced management cost;

Automatic dosing unit for utilization with any type of flours and starches (the size should be 60-80mesh);

Machine Picture

Twin Screw Extruder Machine for Pet Dog Food Production Line

Twin Screw Extruder Machine for Pet Dog Food Production Line



Twin Screw Extruder Machine for Pet Dog Food Production Line

Company Information

 Twin Screw Extruder Machine for Pet Dog Food Production Line





Main Product



1 Pet Food Machine



1.1 Pet Food Extruding Line



1.2 Pet Treats Extruding Line



1.3 Pet Treats Molding Machine



1.4 Pet Biscuit Processing Line



1.5 Rawhide Bone Pressing Machine



 Twin Screw Extruder Machine for Pet Dog Food Production Line

Twin Screw Extruder Machine for Pet Dog Food Production Line



Twin Screw Extruder Machine for Pet Dog Food Production Line

FAQ



1. Could we visit your factory to check the machine carefully and closely?



Youre more than welcome to visit Eagle, will provide machine test running, face to face discussion and turnkey project design solution.





2. Could you afford technician team to guide our installation and commissioning?



Oversea commissioning service provided, our technician will help to install the machine, and teach local workers about operation and maintenance. Buyer should pay for the technician's round flight ticket, accommodation and salary.





3. How long is your machine's guarantee time?



One year since the machine arrive your factory.



4. If some parts break after warranty, what should we do?



Eagle supply full-life after sales service, whenever new parts needed, we will help to supply new ones at reasonable

 price & in shortest time.





5. If we show our workshop size, can you design layout for the whole line?



Auto CAD layout will be provided as clients workshop size.





6. What is the material of the machine?



Stainless steel, especially parts contacting with materials, conforming to food grade.



Twin Screw Extruder Machine for Pet Dog Food Production Line
