Hot Runner System Pet Injection Molding Machine for Dog Treats

Hot Runner System Pet Injection Molding Machine for Dog Treats photo-1
Hot Runner System Pet Injection Molding Machine for Dog Treats photo-2
Hot Runner System Pet Injection Molding Machine for Dog Treats photo-3
Hot Runner System Pet Injection Molding Machine for Dog Treats photo-4
Hot Runner System Pet Injection Molding Machine for Dog Treats photo-5
Hot Runner System Pet Injection Molding Machine for Dog Treats photo-6
US$ 20,000 - 65,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Eagle
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Shandong, China
Brand Name Eagle
Model Number DP-250
Application Other, Pet Food
Voltage 380V/50HZ
Power(W) 90kw
Weight 1500kg
Dimension(L*W*H) 25000*1500*2200
Certification CE ISO
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description



Product Specification


DP-250 Pet Treats Injection Moulding Machine is special machinery for producing pet snacks. With such machine, various shapes can be made, such as hedgehog, crocodile, dog, bone, pork ears, barrel, etc. The shapes are very lovely and it is a ideal encouragement to dogs and cats while they learn a new action or do well in some exercises and games. Also, we can provide different recipes to meet various market demands.


Machine Picture

Hot Runner System Pet Injection Molding Machine for Dog Treats

Hot Runner System Pet Injection Molding Machine for Dog Treats

Sample Picture
  Hot Runner System Pet Injection Molding Machine for Dog Treats

Hot Runner System Pet Injection Molding Machine for Dog Treats


Technical Parameter





Item

Name of item

Unit

DP-250

Injection Unit

Screw Diameter

mm

55

Screw L/D Ratio

Ratio

20

Injection Volume (Theoretical)

cm

640

Injection Weight (PE)

g

582

Injection Speed

g/s

224

Injection Pressure

Mpa

178

Screw Speed

rpm

0-180

Clamping Unit

Clamping Force

KN

2500

Open Stroke

mm

545

Space Between Tie-bars

mm×mm

590 x 590

Min.Mould Height

mm

200

Max.Mould Height

mm

610

Ejector stroke

mm

160

Ejector Force

KN

62

Ejector Rob Quantity

N

8 + 4 + 1

Others

Max. Pump Pressure

Mpa

16

Pump Motor Power

kw

15

Heater Power

kw

18

Machine Dimension (LxWxH)

m x m x m

6.5 x 1.6 x 2.2

Machine Weight

t

9

Mould Positioning Ring Diameter

mm

160

Material Hopper Volume

kg

50

Sphere Radius

mm

SR10







Technical Parameter

1. Screw rotating speed read-out.

2. Security code function to avoid missing data or careless changing.

3. Super low pressure clamping ensures security of user, and maintains lifespan of machine efficiently.

4. The response time of the drive system is very fast. It requires only 0.005s to reach the maximum power output, greatly shorten the cycle time.

5. The precision of processing tolerances to produce the plastic parts will be greatly improved. The optimized rate of repeated qualified parts is around 40-130%.

6. Equipped with a rotary encoder and pressure sensor, the pressure flow state of the energy saving the machine will be transmitted to the controller, the command of which will be sent out to the efficient synchronous servo motor to change the rotation and the torque accordingly.





Company Information

Jinan  Eagle Food Machinery Co.,Ltd. an ISO9001 certified enterprise, specialized in development

and sales of pet food machinery and relative packing machine.

After years of development, Eagle has established a mature sales and agency network.

Eagle machine runs in more than 80 countries including USA, Germany, Italy, Span, Holland,

Australia, Brazil,Mexico, Egypt etc.

All Eagle machines are CE certified with premium quality and stable performance.





Main Products:

1 Pet Food Machine
1.1 Pet Food Extruding Line
1.2 Pet Treats Extruding Line
1.3 Pet Treats Molding Machine
1.4 Pet Biscuit Processing Line
1.5 Rawhide Bone Pressing Machine

Best products about Pet Food Extruder , Dog Food Extruder and Pet Injection Molding Machine.

Hot Runner System Pet Injection Molding Machine for Dog Treats



Hot Runner System Pet Injection Molding Machine for Dog Treats

Hot Runner System Pet Injection Molding Machine for Dog Treats

Our Services

Commissioning Service

1. We make accurate factory layout design according to customer’s factory size; if the customer needed, we could make workshop design with electricity power, water supply, gas power, material storage, final storages, worker’s restroom, etc.

2. After delivering machines to client’s factory, we start to apply for the Visa to client’s country immediately; normally the vessel needs 20-60 days to the required port, so we have enough time to get the Visa. While the machines arrives your factory, our engineers are ready to start for the commissioning service.

3. 1-2 of our engineers will go to your factory to install and adjust the processing line to realize normal production at shortest time.

4. Our engineers have responsibility to train and teach the workers how to operate, clean, maintain and repair all the machines, until the workers could well operate the processing line.

5. It normally costs 10 days for the commissioning
service, and we supply 1 year guarantee from the date of completion of commissioning service.

6. The engineer’s round-trip flight tickets, accommodation and daily salary USD 50 are on client’s account.
