Adjustable screw feeding rail auto screw conveyor feeder
802 screw feeder is our company new R&D products , First of all make some improvement according to the orbit easy deformation, not smooth, block the screws, vulnerable etc shortcomings;802 orbit is choosing Japan imported stainless steel materials, processing after its material hardness up to over 60 degrees, good toughness and no deformation.
The high quality stainless steel material after finishing, smooth, assurance screw can smooth come out.
Screw feeder vibration part is an area of high malfunctioning, we will this with our patent technology improved (the technology temporary not open, this not as a detailed description), 808 performance and stability is ascension.
1) Imported orbit materials, good toughness, and smooth, not block screw, durable.
2) Patent design vibrator, vibrator always vibration, never stop.
3) Guide Tsui fluctuation adjusted by screw, convenient and accurate, adjust distance can be accurate to 0.01 mm.
4) Brush fluctuation adjusted by screw, very convenient.
5) 808 type with screw counting function: set A single product Shared screw quantity, cycling and counting ways to additive or decline. B lock screws total records, can count a machine total records a period out of the screw.
6) Adjust orbit randomly, suitable for screw diameter range 1.0 mm to 5.0 mm, it also suitable for diameter 1.0 mm screw.
Technical parameters
| Model | 802 | |
| Dimension | 123(W)×181(D)×145(H)mm | |
| Weight | 2.9Kg | |
| DC Power supply | AC220V, DC12V500mA AC ADAPTER | |
| thread form : | M screw & self-tapping | |
| screw material | ferrous metal | |
| Screw length range | less 20mm | |
| orbit adjustment range | 1.0mm-5.0mm | |
| continuous pickup speed | 1.5S/pc | |
| Screw counter amount | 9999(pcs) | |
| Total accumulative amount | 9999*9999(pcs) | |
