Specifications
With its four stroke engine,the consumption of fuel is less and the cost is low.Features
1. With its four stroke engine,the consumption of fuel is less and the cost is low.
2. Special design for preventing noise,and the noise is low when working
3. Hign efficiency and precise cutting.
Application scope:
Cement,bituminous concrete pavement,the cutting of expansion joint of square,the cutting when repairing concrete pavement ,the cutting of various kinds of concrete member.
Technical parameters:
model | MCD-220DXH | KQS400R |
weight | 138kg | 85kg |
applicable blade diameter | 500mm | 350mm/400mm |
thickness | 2.5mm/3.2mm | 2.5mm/3.2mm |
aperture | 25.4mm/50mm | 25.4mm/50mm |
max cutting depth | 95mm/200mm | 170mm |
water tank capacity | 45L | 15L |
engine | HONDA GX270/390 | HONDA GX270/390 |
saw blade rotation direction | undercutting | undercutting |
forward way | manual implementation | manual implementation |
