Screw and barrel for Injection Molding Machine

Name: Screw and barrel for Injection Molding Machine
Brand: Tizatech
Price: USD $100 - 1000 / Set

FOB Price

USD $100 - $1000 / Set

1 Set(Min.Order)

Product Details

Brand Name:

Tizatech

Place of Origin:

China

Model Number:

Haitian Tizatech001

Over 29 years experience in screw and barrel , more info pls find kaylee(at)

Specification:

Diameter: Ø15-Ø500

L/D ratio:15-55

Base Materials:	1)38CrMoAlA(SACM 645) 2)42CrMo(AISI 4140) 3)Cr12MoV(SKD11) 4)4Cr5MoSiV1(SKD61) 5)9Cr18MoV 6)40Cr
Bimetallic Alloy Materials:	1)Fe-based alloy 2)Ni-based alloy 3)Co-based alloy 4)Tungsten carbide
Processing Technology:	Heat treatment High-frequency quenching Nitriding treatment Hard-chrome electroplating Bimetallic alloy welding
Technical Parameter:	Nitrided layer depth:0.50-0.80mm Nitrided hardness: 900-1100HV Nitrided brittleness: Less than 2 level Surface roughness: Ra 0.4 Linearity of screw: 0.015mm Hard-chrome plating hardness: ≥950HV Chrome-plating layer depth: 0.025~0.10mm Bimetallic layer depth: 2 mm Bimetallic hardness: HRC50-65
Material to be extruded:	PP, PE, PVC, ABS, AS, PS etc.

We can manufacture all types of screws and barrels according to clients’ requirement
