Reefer Van Fridge Box Truck

Specifications

Reefer Van Fridge Box Truck
1)JMC chassis van truck
2)Capcity 8 ton-10ton van
3)Good Cooling effect
4)Temperature:-18-20

1.The advantage of J MC Reefer Van Fridge Box Truck

1).Cooling effect,PU insulated Material, Fiber-glass Reinforced Plastic

2).Energy saving

3).Driving Comfort

4).High safety design

5).capacity:8 tons-10 tons

6).temperature:-18-20

7). High efficient and comfortable ergonomic space
8).Technical equipment leading in market

Reefer Van Fridge Box Truck
1)JMC chassis van truck
2)Capcity 8 ton-10ton van
3)Good Cooling effect
4)Temperature:-18-20

-----------------------------------------------------------------------------------------------------------------------------

2.The Specifications of Refrigerator  free-er Trucks ZZT 5160XLC



Model			ZZT5160XLC
CHASSIS	Model and ID NO.		HFC1162K3R1GZT /1243660
	Manufacturer		JMC Automobile Co., LTD
	Axle		2
	Wheelbase(mm)		5300
	Wheel Track(Front/Rear mm)		1830/1800
	Tyre Size		8.25-20,9.00-20
	Tyre		6
ENGINE	Model		YC4E140-33
	Manufacturer		JMC Automobile  Co., LTD
	Delivery Capacity(ml)		4260
	Fuel		Disel
	Rated Power(Kw)		105
	Emission Standard		GB17691-2005,GB3847-2005
FRAME	Front	Type	Steel Plate Spring
		Quantity	9
	Rear	Type	Steel Plate Spring
		Quantity	9+7
CAR LOAD	Dimension Parameters	Overall Dimensions(mm)	8980*2495*3750
		L*W*H
		Interior Cargo Body Dimentions(mm)	6750*2285*2300
		L*W*H
		Cubage(m3)	35m³
		Front Overhang/Rear Overhang(mm)	1235/2445
	Quality Parameters	Approch Angle/Departure Angle(°)	30/12
		Curb Weight(Kg)	7030
		Rated Payload(Kg)	8285
		Gross Vehicle Weight(Kg)	15510
	Max. Speed(km/h)		98
	Person In Cab(Persons)		3

-----------------------------------------------------------------------------------------------------------------------------

3.Sale points of Foton refrigerator truck
1).high quality
2).low price
3).best configuration
4).low fuel consumption

5).excellent performance

6).high speed

7).heavy load capacity

8).advanced skills

-----------------------------------------------------------------------------------------------------------------------------

4. Our company main products:

We can supply: refrigerated truck body, insulated truck body, dry cargo truck body, plateform truck body, explosion-proof truck body, dump truck body,tank truck body, wing opening truck body, catering truck body, any other special purpose truck and truck body.....etc.
