Sino truck Sitong fence semi trailer cargo utility trailer
Specifications
Tare Weight | 8.3T |
dimension | 13000mm*2490mm*2860mm(outside dimension) 12800*2300*1800mm(inside dimension) |
Loading Capacity | ≤60T |
Axle | 13T/16T,FUWA/BPW/Huajing Brand |
Rim | 9.00-22.5 |
Tire | 12.00R22.5/315 80R22.5 |
Suspension | Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW Brand) |
Spring leaf | 90(w)mm*13(thickness)mm*10Layer or 100mm*12mm*12 |
King pin | Jost brand 2.0 0r 3.5 inch bolts type or welding type |
Support leg | JOST brand D200T or China brand 28Tons (Double speed) |
Main beam | Height:500mm,upon plate is 14mm,middle plate is 8mm,down plate is 16mm;Material is Q345B Steel |
Side beam | 16mm or 18mm channal steel (Material is Q235steel) |
Brake chamber | WABCO RE 6 relay valve;T30/30+T30 Spring brake chamber |
ABS | Optional |
Twist Locks | Four,Eight, Twelve pieces(Lifting type or Twist Screw Type) |
Valve | WABCO valve |
Light | LED light |
Voltage | 24V |
Receptacle | 7 ways(7 wire harness) |
Tool box | One piece,1m*0.5m*0.5m(Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
Painting | Complete Chassis sand blasting to clean rust,1 coat of anticorrosive prime,2coats of final paint |
Shipping term | Transport by bulk cargo carrier, RORO or 40HQ container |
Pictures
1. Item: 40ft container truck semi flatbed trailer
2. shipping way: RORO, bulk ship, 45ft container.
3. package:
A. Nude Packing 3 sets stacked (by Bulk Cargo Ship, Ro-ro Ship, or Land Transportation) ;
B. Keep the trailer original but load three sets in one 45ft container.
Due to 14 years' technical experience ,we can offer high quality but low price.Besides,the producing process is strict and quick,customers' goods will be ready for shipment within 15days after we receive the deposit.
1. OEM Service
2. Production Solutions Service
3. Customized Service
4.Quality Guarantee
company profile
CNHTC Liangshan Sitong Special Automobile Co., Ltd
CNHTC Liangshan Sitong Special Automobile Co., Ltd. is the appointed manufacturing enterprise listed in the bulletin of Ministry of Information Technology and belongs to a joint venture of China National Heavy Duty Truck Group Co., Ltd. Its leading products include low-bed trailers, bulk lorries, delivery vans, and box stake semi-trailers; tank trucks, dump trucks and special vehicles, and other more than 100 kinds of products. It undertakes the modification and the design of dedicated vehicles and special vehicles. The company is engaged in providing the most high-quality high-way transportation products. It is also a domestic famous manufacturer of special vehicles engaged in the development, manufacturing and sales.
It is located in manufacturing base of China’s trailer (special vehicle)—Quanpu Industrial Zone, Liangshan, Shandong, with an area of more than 100,000m2 and total assets of RMB 81 million. The company is sharp at manufacturing and R&D, has domestically leading manufacturing equipment and technology, and owns professional product inspection line and a complete CAD system, which attributes to the winning of CCC certificate, IS09001 Quality Management Certification and “National Qualified Enterprise of Special Vehicle Quality Steadiness” in 2005. Over the years, the company’s “Lufeng” special vehicles sell well in China and overseas market and win great satisfaction and trust from customers.
Production Capacity
Certificate
Factory Pictures
Ralated products
If you are interested in our products,please feel free to contact:
Anne Shi
CNHTC Liangshan Sitong Special Automobile Co., Ltd.
Phone number:+8613098850043
Skype: manfei0409
Fax:+86 537 2882988
